Brother MFC-J2310 Service Manual

5-33
Confidential
1.3.18 Cartridge IC Communication Check (Maintenance mode 57)
< Function >
This function checks the applicable cartridge, color information, destination, size and data
version in the IC chip built in an ink cartridge.
< Operating Procedure >
(1) Press the 5 and 7 keys in this order in the initial stage of the maintenance mode.
The "IC ACT ALL" appears on the LCD.
To check whether the cartridge is applicable,
press the 1 key. The "IC ACT ALL" appears
on the LCD.
To check the color information of the cartridge,
press the 2 key. The "IC COL ALL"
appears on the LCD.
To check the destination of the cartridge,
press the 3 key. The "IC AREA ALL" appears on
the LCD.
To check the cartridge size,
press the 4 key. The "IC SIZE ALL" appears on the LCD.
To check the data version of the cartridge,
press the 5 key. The "IC VER BLACK" appears
on the LCD.
(2) Select the slot number of the cartridge to be checked, using the or key.
ALL: all colors (except MAIN)
BLACK: black
MAGENTA: magenta
CYAN: cyan
YELLOW: yellow
MAIN: IC chip in the machine
Note: The color displayed on the LCD indicates not the cartridge color but the cartridge
slot color position.
(3) Press the Mono Start key.
If checking is successfully completed, the LCD shows "OK."
If any error is detected, the LCD shows the corresponding error code as shown below. Press
the Stop key to return the machine to the initial stage of the maintenance mode.
Display Causes
NG0 to NG99 Failure of IC integrated in the machine
NG100 to NG199 No response from the IC
• Ink cartridge not loaded
• No IC in the ink cartridge
• IC contact defective
NG200 to NG299 Wrong response result from the IC
• Cartridge defective
NG300 to NG399 Succeeded in verifying IC, but the information judged as
mismatching
• Loading mistake
