Brother MFC-J2310 Service Manual

5-62
Confidential
1.3.32 Display of the Equipment's Log (Maintenance mode 80)
< Function >
This function displays the log information on the LCD.
< Operating Procedure >
(1) Press the 8 and 0 keys in this order in the initial stage of the maintenance mode.
The "00:00 22:36 OK" appears on the LCD.
(2) Press the key to call up the following log information items, one by one.
To return to the previous item, press the key.
(3) Press the X key to return the machine to the initial stage of the maintenance mode.
Log information items
Items shown on the LCD Description
00:00 22:36 OK
RTC backup check, OK: Backup completed, NG: Backup failed
Not shown on DCP models. *2
8CA-R65-001 Model code
COUNTRY:0001 Country code
SWITCH:82 Checksum of WSW, PSW, USW, and FSW *2
MAIN:0A307211213 Main firmware version and ROM production date & time
3415 5314 Main firmware checksum/ROM1 checksum
B0306101054:34CD Boot ROM production date & time and checksum *2
S/N: Serial number *1
ALR777FFFFFF8 Head property information
CISF:00 CISA:00 CIS type, CISF: First side CIS, CISA: Second side CIS
ENGINE:00 Engine type *2
PICTBRIDGE PictBridge information *2
DK:0000000000000 Ink drop count *3
SEN K:0000000001 Ink drop count after detection of "Ink Low" *3
PLA K:0000000001 Ink drop count for droplets jetted out onto the platen *3
LK:0000000000001 Total dot count *3
INK_CH BK:00001 Ink cartridge change count (high-yield) *3
INK_CH2 BK:00001 Ink cartridge change count (super high-yield) *3
CHGMISS_BK:00001 Ink cartridge detection failure count *3
PAGE:0000000002 Total printed page count *4
JAM:00001 Total jam count
PC:00001 PC print page count *5
COPY:00002 Total number of copies *5
FAX:00001 Total number of fax/list/report prints *5
MEDIA:00001 Memory card/PictBridge print page count
TEST PRINT:0000 Total number of test prints
A3P:00001 Total page count for paper sizes and types *6
DX P:0000000001 Total page count in duplex printing
DX JAM:00001 Jam count in duplex printing
DX CLEAN:001 Roller cleaning count in duplex printing
