Delta EtherCAT User Manual

Operation of DI/DO Module EtherCAT Programming Guide
18-10 March, 2017
18
18.8 _ECAT_Slave_DIO_Set_Output_Error_Value

Syntax
U16 PASCAL_ECAT_Slave_DIO_Set_Output_Error_Value (U16 CardNo, U16 NodeID,
U16SlotNo, U16 Value)

Purpose
This is for setting the retentive status of each channel on remote DO module when EtherCAT
communication is disconnected.
Note: Please use _ECAT_Slave_DIO_Set_Output_Error_Mode (see section 18.7) to enable the retentive
function when EtherCAT communication is disconnected.

Parameter
Name Data type Unit Description
CardNo U16 Number Card No.
NodeID U16 Number Node ID
SlotNo U16 Number Slot ID
Value U16 Value
Bit0 ~ 15 represent the output channels Y0~Y15
respectively.
0: Output channel is off
1: Output channel is on

Example
U16 Status;
U16 CardNo=16, NodeID=1, SlotNo=0;
// Change the function of the first 8 channels to retentive function when communication is
disconnected.
U16 Value=0x0F;
Status=_ECAT_Slave_DIO_Set_Output_Error_Value (CardNo, NodeID, SlotNo, Value);

Delta EtherCAT Specifications

General

Category	Control Systems
Communication Interface	EtherCAT
Data Transfer Rate	100 Mbps
Number of Slaves	Up to 65535
Synchronization Accuracy	< 1 μs
Supported Standards	IEC 61158, IEC 61784
Topology	Star, Tree
Cable Type	Ethernet (CAT5e or higher)
Maximum Cable Length	100 meters (between nodes)

Summary

EtherCAT Operation Example

EtherCAT Initialization

Demonstrates the process of initializing EtherCAT communication, including activating and finding interface cards.

EtherCAT Master Configuration

_ECAT_Master_Set_CycleTime

Explains the API for setting the EtherCAT master communication cycle time before initialization.

Master Initialization

_ECAT_Master_Open

Explains the essential API for controlling the Delta EtherCAT master, checking card quantity, and creating memory blocks.

_ECAT_Master_Initial

Describes the API for initializing EtherCAT communication and switching slaves to OP mode.

General Operation of Motion Axis

_ECAT_Slave_Motion_Set_Svon

Describes the API for setting the servo motor to ON/OFF state.

_ECAT_Slave_Motion_Ralm

Cyclic Synchronous Position Mode (CSP)

_ECAT_Slave_CSP_Start_Move

Details the API for executing linear interpolation of a single axis in CSP mode.

_ECAT_Slave_CSP_Start_V_Move

Homing

_ECAT_Slave_Home_Config

Details the API for setting the homing mode and parameters for motion axes.

_ECAT_Slave_Home_Move

Explains the API for executing the homing procedure on a specified motion axis.

Profile Position Mode (PP)

_ECAT_Slave_PP_Start_Move

Describes the API for executing single-axis linear motion in PP mode.

Profile Velocity Mode (PV)

_ECAT_Slave_PV_Start_Move

Explains the API for executing single-axis motion with constant speed in PV mode.

Group Motion Control

_ECAT_Slave_User_Motion_Control_Set_Enable_Mode

Describes the API for setting the group status and enabling/disabling group motion control.

Operation of Delta Servo System

_ECAT_Slave_DeltaServo_Write_Parameter

Explains the API for writing servo parameter values to Delta servo drives.

_ECAT_Slave_DeltaServo_Read_Parameter

Details the API for reading servo parameter values from Delta servo drives.

Auto Recording Function of Motion Axis

High-Speed Pulse Compare Function

_ECAT_Compare_Set_Channel_Position

Security of Software Protection

_ECAT_Security_Check_Verifykey

_ECAT_Security_Check_UserPassword

MPG Operation (For R1-EC5614D0 Series)

_ECAT_Slave_R1_EC5614_Set_MJ_Config

Sets the parameters for the MPG (Manual Pulse Generator) function.

_ECAT_Slave_R1_EC5614_Set_MJ_Enable

Error Code Description

List of error code

Lists returned values (decimal) and corresponding error code names for EtherCAT DLL operations.

Error code description

Provides detailed descriptions and troubleshooting steps for various EtherCAT error codes.
