Delta EtherCAT User Manual

Operation of Pulse Module (R1-ECx62xD0 Series) EtherCAT Programming Guide
21-4 March, 2017
21
21.2 _ECAT_Slave_R1_ECx62x_Set_Input_Mode

Syntax
U16 PASCAL _ECAT_Slave_R1_ECx62x_Set_Input_Mode (U16 CardNo, U16 AxisNo, U16
SlotNo, U16 RangeMode)

Purpose
This is for setting the type of pulse input.

Parameter
Name Data type Property Description
CardNo U16 Number Card No.
AxisNo U16 Number Node ID
SlotNo U16 Number Slot ID
Mode U16 Option
0: A/B Phase
1: CW/CCW
2: PLS/DIR

Example
U16 Status = 0;
U16 CardNo=16, AxisNo =1, SlotNo=0;
U16 Mode=1;
Status= _ECAT_Slave_R1_ECx62x_Set_Input_Mode (CardNo, AxisNo, SlotNo, Mode);
