Delta EtherCAT User Manual

EtherCAT Operation Example EtherCAT Programming Guide
3-12 March, 2017
3
3.4 Constant speed control
3.4.1 Function list
Function name
_ECAT_Slave_PV_Start_Move
_ECAT_Slave_Motion_Sd_Stop
 Properties
Hardware EtherCAT RTX (PAC) EtherCAT motion card
Supported
Y Y
3.4.2 Application examples
Program interface
Figure 3.4.2.1
(1) Activate and initialize interface card
Press the Initial Card key (as shown in figure 3.4.2.1) to start initializing the interface card.
Press the Find Slave key (as shown in figure 3.4.2.1) to start searching the connecting
modules.
For more information about the interface card initialization, please see “Activate interface
card” and “Initialize interface card” in section 3.1.2.
