Serial port Add a USB console port
Digi Connect IT® 16/48 User Guide
166
10. Set the type of flow control used by the device to which you want to connect:
(config)> serial port1 flow type
Allowed values are:
n none
n rts/cts
n xon/xoff
The default is none.
11. Reversed mode is disabled by default. To enable:
(config)> serial port1 reversed_mode true
To disable reversed mode:
(config)> serial port1 reversed_mode false
12. Save the configuration and apply the change:
(config)> save
Configuration saved.
>
13. Type exit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
Add a USB console port
Your Connect IT 16/48 can be configured to support USB-to-serial adapters for console access to the
device, remote serial out-of-band (OOB) access to other devices, or for use in python applications. The
following USB-to-serial chipsets are supported:
n FTDI
n Prolific
To add a USB console port:
WebUI
1. Log into the Connect IT 16/48 WebUI as a user with full Admin access rights.
2. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Serial.
