Routing Virtual Router Redundancy Protocol (VRRP)
Digi Connect IT® 16/48 User Guide
231
b. Set the end address to 250:
(config)> network interface eth2 ipv4 dhcp_server lease_end 250
(config)>
3. Set the DHCP server gateway type to custom:
(config)> network interface eth2 ipv4 dhcp_server advanced gateway custom
(config)>
4. Set the custom gateway to 192.168.3.3:
(config)> network interface eth2 ipv4 dhcp_server advanced gateway_custom
192.168.3.3
(config)>
5. Save the configuration and apply the change:
(config)> save
Configuration saved.
>
6. Type exit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
Show VRRP status and statistics
This section describes how to display VRRPstatus and statistics for a Connect IT device. VRRP status
is available from the Web UI only.
WebUI
1. Log into the Connect IT 16/48 WebUI as a user with full Admin access rights.
2. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Status > VRRP.
The Virtual Router Redundancy Protocol window is displayed.
