10 Unidrive M702 User Guide
Issue Number: 3
2 Product information
2.1 Introduction
Universal AC and servo drive
This product family consists of Unidrive M700, Unidrive M701 and Unidrive M702, delivering maximum machine performance.
Common features (Unidrive M700, 701 and 702)
• Universal high performance open and closed loop control for induction, servo, permanent magnet and linear motors
• Automation and motion option module for direct migration of SyPTPro / SM-Applications programs
• Onboard IEC 61131-3 programmable automation and motion control
• Flexibility with speed and position measurement, supporting multiple devices and all common interfaces
• NV Media Card for parameter copying and data storage
Optional features (Unidrive M700, 701 and 702)
• Select up to three option modules including programmable automation and motion control.
Unidrive M700
• Ethernet fieldbus communications
• Single channel SAFE TORQUE OFF (STO) input
Unidrive M701
• Provides a direct replacement / upgrade for Unidrive SP
• 485 serial communications interface
• Single channel SAFE TORQUE OFF (STO) input
Unidrive M702
• Ethernet fieldbus communications
• Dual channel SAFE TORQUE OFF (STO) input
2.2 Model number
The way in which the model numbers for the Unidrive M700 range are formed is illustrated below:
Figure 2-1 Model number
Optional Build
Identification Label
Derivative Electrical Specifications
M700 - 03 4 00078
Unidrive M700
Product Line
700 - Ethernet
701 - 485
Frame Size:
Voltage Rating:
Current Rating:
Heavy Duty current rating x 10
Drive Format:
A - AC in AC out
Customer Code
01
A B 1 00
Customer Code:
00 = 50 Hz
01 = 60 Hz
Reserved:
Conformal Coating:
0 = Standard
IP / NEMA Rating:
1 = IP21 / NEMA 1
Brake Transistor:
B = Brake
Cooling:
A = Air
Reserved
01
A
Documentation
1
Documentation:
0 - Supplied separately
1 - English
702 - Ethernet,2xSTO
2 - 200 V (200 - 240
- 400 V (380 - 480
- 575 V (500 - 575
- 690 V (500 - 690
± 10 %)
4 ±
±
±
10 %)
510%)
610%)
