11.21 Menu 24: Ethernet status and monitoring
22.058 Parameter 00.058 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.059 Parameter 00.059 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.060 Parameter 00.060 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.061 Parameter 00.061 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.062 Parameter 00.062 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.063 Parameter 00.063 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.064 Parameter 00.064 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.065 Parameter 00.065 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.066 Parameter 00.066 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.067 Parameter 00.067 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.068 Parameter 00.068 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.069 Parameter 00.069 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.070 Parameter 00.070 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.071 Parameter 00.071 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.072 Parameter 00.072 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.073 Parameter 00.073 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.074 Parameter 00.074 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.075 Parameter 00.075 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.076 Parameter 00.076 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.077 Parameter 00.077 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.078 Parameter 00.078 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.079 Parameter 00.079 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.080 Parameter 00.080 Set-up 0.000 to 59.999 0.000
RW Num PT US
RW Read / Write RO Read only Num Number parameter Bit Bit parameter Txt Text string Bin Binary parameter FI Filtered
ND No default value NC Not copied PT Protected parameter RA Rating dependent US User save PS Power-down save DE Destination
Parameter
Range Default
Type
OL RFC-A RFC-S OL RFC-A RFC-S
24.001 Module ID 0 to 65535 RO Num ND NC PT
24.002 Software Version 00.00.00.00 to 99.99.99.99 RO Num ND NC PT
24.003 Hardware Version 0.00 to 99.99 RO Num ND NC PT
24.004 Serial Number LS 00000000 to 99999999 RO Num ND NC PT
24.005 Serial Number MS 0 to 99999999 RO Num ND NC PT
24.006 Status
Bootldr-Update (-2), Bootldr-Idle (-1),
Initializing (0), OK (1), Config (2), Error (3)
RO Txt ND NC PT
24.007 Reset Off (0) or On (1) Off (0) RW Bit NC
24.008 Default Off (0) or On (1) Off (0) RW Bit NC
24.009 Active Alarm Bits 0000000000000000 to 1111111111111111 0000000000000000 RO Bin NC
24.010 Active IP Address 128.0.0.0 to 127.255.255.255 0.0.0.0 RO IP NC PT
Parameter
Range(
) Default()
Type
OL RFC-A RFC-S OL RFC-A RFC-S
RW Read / Write RO Read only Num Number parameter Bit Bit parameter Txt Text string Bin Binary parameter FI Filtered
ND No default value NC Not copied PT Protected parameter RA Rating dependent US User save PS Power-down save DE Destination
IP IP address Mac Mac address Date Date parameter Time Time parameter SMP Slot,menu,parameter Chr Character parameter Ver Version number
