11.21.5 Slot 4 Menu 11: Synchronization
Parameter
Range Default
Type
OL RFC-A RFC-S OL RFC-A RFC-S
4.11.001 Preferred Sync Master 0 to 4 1 RW Num US
4.11.002 Master Clock Domain 0 to 3 0 RW Num US
4.11.005 Grandmaster MAC Address 00:00:00:00:00:00 to FF:FF:FF:FF:FF:FF RO Mac ND NC PT
4.11.006 Synchronization Jitter From Grandmaster -2147483648 to 2147483647 ns RO Num ND NC PT
4.11.007 Synchronization Jitter Threshold 10 to 4294967295 1000 RW Num US
4.11.008 Module Synchronized Flag Off (0) or On (1) Off (0) RO Bit
4.11.009 Inhibit Drive Synchronization Off (0) or On (1) Off (0) RW Bit US
4.11.010 PTP Date 00-00-00 to 31-12-99 RO Date ND NC PT
4.11.011 PTP Time 00:00:00 to 23:59:59 RO Time ND NC PT
4.11.013 Network Transport Layer Select 802.3 (0), UDP (1) UDP (1) RW Txt US
4.11.014 1 Step Clock Correction Off (0) or On (1) Off (0) RW Bit US
4.11.015 PTP Delay Measurement Select E2E DELAY (0), P2P DELAY (1) P2P DELAY (1) RW Txt US
4.11.016 PTP Sync Rate -4 to 4 -2 RW Num US
4.11.020 Network Error Count 0 to 4294967295 RO Num ND NC PT
4.11.022 Interoption Sync Status
MASTER (0), PRODUCER (1),
INDEPENDENT (2)
RO Txt ND NC
4.11.030 Tx1 Link Maximum Network Delay 0 to 100 ms 0 ms RW Num US
4.11.031 Tx2 Link Maximum Network Delay 0 to 100 ms 0 ms RW Num US
4.11.032 Tx3 Link Maximum Network Delay 0 to 100 ms 0 ms RW Num US
4.11.040 Rx1 Late Synchronization Frame Action Off (0), Trip (1), Do not use (2), Use (3) Off (0) RW Txt US
4.11.041 Rx1 Late Synchronization Frame Destination
This slot (0), Slot 1 (1), Slot 2 (2),
Slot 3 (3), Slot 4 (4)
This slot (0) RW Txt US
4.11.042 Rx1 Late Synchronization Frame Event
No event (0), Event (1), Event1 (2),
Event2 (3), Event3 (4)
No event (0) RW Txt US
4.11.050 Rx2 Late Synchronization Frame Action Off (0), Trip (1), Do not use (2), Use (3) Off (0) RW Txt US
4.11.051 Rx2 Late Synchronization Frame Destination
This slot (0), Slot 1 (1), Slot 2 (2),
Slot 3 (3), Slot 4 (4)
This slot (0) RW Txt US
4.11.052 Rx2 Late Synchronization Frame Event
No event (0), Event (1), Event1 (2),
Event2 (3), Event3 (4)
No event (0) RW Txt US
4.11.060 Rx3 Late Synchronization Frame Action Off (0), Trip (1), Do not use (2), Use (3) Off (0) RW Txt US
4.11.061 Rx3 Late Synchronization Frame Destination
This slot (0), Slot 1 (1), Slot 2 (2),
Slot 3 (3), Slot 4 (4)
This slot (0) RW Txt US
4.11.062 Rx3 Late Synchronization Frame Event
No event (0), Event (1), Event1 (2),
Event2 (3), Event3 (4)
No event (0) RW Txt US
RW Read / Write RO Read only Num Number parameter Bit Bit parameter Txt Text string Bin Binary parameter FI Filtered
ND No default value NC Not copied PT Protected parameter RA Rating dependent US User save PS Power-down save DE Destination
IP IP address Mac Mac address Date Date parameter Time Time parameter SMP Slot,menu,parameter Chr Character parameter Ver Version number
