Unidrive M702 User Guide 47
Issue Number: 3
3.12 Electrical terminals
3.12.1 Location of the power and ground terminals
Figure 3-42 Locations of the power and ground terminals
Key
1. Control terminals 4. Ground connections 7. DC bus -
2. Relay terminals 5. AC power terminals 8. DC bus +
3. Additional ground connection 6. Motor terminals 9. Brake terminal
