Unidrive M702 User Guide 245
Issue Number: 3
12.2 Optional external EMC filters
Table 12-37 EMC filter cross reference
12.2.1 EMC filter ratings
Table 12-38 Optional external EMC filter details
12.2.2 Overall EMC filter dimensions
Table 12-39 Optional external EMC filter dimensions
Model CT part number
200 V
03200050 to 03200106 4200-3230
04200137 to 04200185
05200250
06200330 to 06200440 4200-2300
07200610 to 07200830
08201160 to 08201320
400 V
03400025 to 03400100 4200-3480
04400150 to 04400172
05400270 to 05400300
06400350 to 06400470 4200-4800
07400660 to 07401000
08401340 to 08401570
575 V
05500030 to 05500069
06500100 to 06500350 4200-3690
07500440 to 07500550
08500630 to 08500860
690 V
07600190 to 07600540
08600630 to 08600860
CT part
number
Maximum
continuous current
Voltage rating
IP rating
Power dissipation at
rated current
Ground leakage
Discharge
resistors
Balanced supply
phase-to-phase
and
phase-to-ground
Worst case@ 40 °C
(104 °F)
@ 50 °C
(122 °F)
IEC UL
@ 40 °C
(104 °F)
@ 50 °C
(122 °F)
A A V V W W mA mA MΩ
4200-3230 20 18.5 250 300
20
20 17 2.4 60
1.5
4200-3480 16 15 528 600 13 11 11 151
4200-2300 55 51 250 300 41 35 4.2 69
4200-4800 63 58 528 600 54 46 11.2 183
4200-3690 42 39 760 600 45 39 12 234
CT part
number
Dimension (mm)
Weight
HWD
mm inch mm inch mm inch kg lb
4200-3230
372 14.65 80 3.15 41 1.61
1.9 4.20
4200-3480 2.0 4.40
4200-2300
434 17.09 210 8.27 60 2.36
6.5 14.30
4200-4800 6.7 14.80
4200-3690 7.0 15.40
