Emerson Unidrive M702 User Manual

Safety
information
Product
information
Mechanical
installation
Electrical
installation
Getting
started
Basic
parameters
Running
the motor
Optimization
NV Media Card
Operation
Onboard
PLC
Advanced
parameters
Technical
data
Diagnostics
UL listing
information
216 Unidrive M702 User Guide
Issue Number: 3
11.20 Menu 22: Additional Menu 0 set-up
Parameter
Range(
)Default()
Type
OL RFC-A RFC-S OL RFC-A RFC-S
22.001 Parameter 00.001 Set-up 0.000 to 59.999 1.007 RW Num PT US
22.002 Parameter 00.002 Set-up 0.000 to 59.999 1.006
RW Num PT US
22.003 Parameter 00.003 Set-up 0.000 to 59.999 2.011
RW Num PT US
22.004 Parameter 00.004 Set-up 0.000 to 59.999 2.021
RW Num PT US
22.005 Parameter 00.005 Set-up 0.000 to 59.999 1.014
RW Num PT US
22.006 Parameter 00.006 Set-up 0.000 to 59.999 4.007
RW Num PT US
22.007 Parameter 00.007 Set-up 0.000 to 59.999 5.014 3.010
RW Num PT US
22.008 Parameter 00.008 Set-up 0.000 to 59.999 5.015 3.011
RW Num PT US
22.009 Parameter 00.009 Set-up 0.000 to 59.999 5.013 3.012
RW Num PT US
22.010 Parameter 00.010 Set-up 0.000 to 59.999 5.004 3.002
RW Num PT US
22.011 Parameter 00.011 Set-up 0.000 to 59.999 5.001 3.029
RW Num PT US
22.012 Parameter 00.012 Set-up 0.000 to 59.999 4.001
RW Num PT US
22.013 Parameter 00.013 Set-up 0.000 to 59.999 4.002
RW Num PT US
22.014 Parameter 00.014 Set-up 0.000 to 59.999 4.011
RW Num PT US
22.015 Parameter 00.015 Set-up 0.000 to 59.999 2.004
RW Num PT US
22.016 Parameter 00.016 Set-up 0.000 to 59.999 0.000 2.002
RW Num PT US
22.017 Parameter 00.017 Set-up 0.000 to 59.999 8.026 4.012
RW Num PT US
22.018 Parameter 00.018 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.019 Parameter 00.019 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.020 Parameter 00.020 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.021 Parameter 00.021 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.022 Parameter 00.022 Set-up 0.000 to 59.999 1.010
RW Num PT US
22.023 Parameter 00.023 Set-up 0.000 to 59.999 1.005
RW Num PT US
22.024 Parameter 00.024 Set-up 0.000 to 59.999 1.021
RW Num PT US
22.025 Parameter 00.025 Set-up 0.000 to 59.999 1.022
RW Num PT US
22.026 Parameter 00.026 Set-up 0.000 to 59.999 1.023 3.008
RW Num PT US
22.027 Parameter 00.027 Set-up 0.000 to 59.999 1.024 3.034
RW Num PT US
22.028 Parameter 00.028 Set-up 0.000 to 59.999 6.013
RW Num PT US
22.029 Parameter 00.029 Set-up 0.000 to 59.999 11.036
RW Num PT US
22.030 Parameter 00.030 Set-up 0.000 to 59.999 11.042
RW Num PT US
22.031 Parameter 00.031 Set-up 0.000 to 59.999 11.033
RW Num PT US
22.032 Parameter 00.032 Set-up 0.000 to 59.999 11.032
RW Num PT US
22.033 Parameter 00.033 Set-up 0.000 to 59.999 6.009 5.016 0.000
RW Num PT US
22.034 Parameter 00.034 Set-up 0.000 to 59.999 11.030
RW Num PT US
22.035 Parameter 00.035 Set-up 0.000 to 59.999 11.024
RW Num PT US
22.036 Parameter 00.036 Set-up 0.000 to 59.999 11.025
RW Num PT US
22.037 Parameter 00.037 Set-up 0.000 to 59.999 11.023
RW Num PT US
22.038 Parameter 00.038 Set-up 0.000 to 59.999 4.013
RW Num PT US
22.039 Parameter 00.039 Set-up 0.000 to 59.999 4.014
RW Num PT US
22.040 Parameter 00.040 Set-up 0.000 to 59.999 5.012
RW Num PT US
22.041 Parameter 00.041 Set-up 0.000 to 59.999 5.018
RW Num PT US
22.042 Parameter 00.042 Set-up 0.000 to 59.999 5.011
RW Num PT US
22.043 Parameter 00.043 Set-up 0.000 to 59.999 5.010 3.025
RW Num PT US
22.044 Parameter 00.044 Set-up 0.000 to 59.999 5.009
RW Num PT US
22.045 Parameter 00.045 Set-up 0.000 to 59.999 5.008 4.015
RW Num PT US
22.046 Parameter 00.046 Set-up 0.000 to 59.999 5.007
RW Num PT US
22.047 Parameter 00.047 Set-up 0.000 to 59.999 5.006 0.000
RW Num PT US
22.048 Parameter 00.048 Set-up 0.000 to 59.999 11.031
RW Num PT US
22.049 Parameter 00.049 Set-up 0.000 to 59.999 11.044
RW Num PT US
22.050 Parameter 00.050 Set-up 0.000 to 59.999 11.029
RW Num PT US
22.051 Parameter 00.051 Set-up 0.000 to 59.999 10.037
RW Num PT US
22.052 Parameter 00.052 Set-up 0.000 to 59.999 11.020
RW Num PT US
22.053 Parameter 00.053 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.054 Parameter 00.054 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.055 Parameter 00.055 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.056 Parameter 00.056 Set-up 0.000 to 59.999 0.000
RW Num PT US
22.057 Parameter 00.057 Set-up 0.000 to 59.999 0.000
RW Num PT US
