268 Unidrive M702 User Guide
Issue Number: 3
Slot4 Error Ethernet interface in slot 4 has detected a fault
252
The Slot4 Error trip indicates that the Ethernet interface in slot 4 on the drive has detected an error. The reason for the trip
can be identified by the sub-trip number.
Recommended actions:
• Identify the reason for the trip from the trip string or from sub-trip number and resolve the error.
• Reset the trip, If the trip persists, Hardware fault - Contact the supplier of the drive.
Trip Diagnosis
Sub-trip Trip string Description
100 Link Loss Network link has been lost
101 E/IP Timeout An EtherNet/IP RPI timeout trip has occurred
102 E/IP Read Param Invalid read consistency parameter
103 E/IP Write Param Invalid write consistency parameter
104 E/IP Fault An unexpected EtherNet/IP error has occurred
105 Modbus Timeout The Modbus connection has timed out
106 DA-RT Timeout DA-RX Rx link has timeout
107 DA-RT Rx Late Rx data was received late
108 INIT Switch
109 INIT PTP
110 INIT DA-RT
111 INIT Modbus
112 INIT SMTP
113 INIT EtherNet/IP
114 INIT TCP/IP
115 Ethernet Failure
200 Software Fault Software Fault
201 BG Overrun Background task overrun
202 Firmware Invalid Firmware is not compatible for the hardware version
203 Drive Unknown Unknown drive type
204 Drive Unsupported Unsupported drive type
205 Mode Unknown Unknown drive mode
206 Mode Unsupported Unsupported drive mode
207 FLASH Error Corrupted Non-volatile FLASH
208 Database Init Database initialization error
209 File System Init File system initialization error
210 Mem Allocation Memory allocation error
211 Filesystem Error File system error
212 Config Save Configuration file save error
213 Over Temperature Option module over temperature
214 Drive Timeout The drive has not responded within watchdog period
215 eCMP Comms Error eCMP communication failure
216 TO eCMP Slot1 eCMP communication to slot 1 timeout
217 TO eCMP Slot2 eCMP communication to slot 2 timeout
218 TO eCMP Slot3 eCMP communication to slot 3 timeout
219 TO eCMP Slot4 eCMP communication to slot 4 timeout
220 I/O Overload Digital output current demand too high
221 Factory Settings Missing factory settings
222 Functional Test Functional test failure
223 Config Restore Configuration file restore error
224 Self Test Error Power on self test error
225 Runtime Config Runtime configuration error
