Unidrive M702 User Guide 223
Issue Number: 3
11.21.6 Slot 4 Menu 15: Modbus
Parameter
Range Default
Type
OL RFC-A RFC-S OL RFC-A RFC-S
4.15.001 Enable Off (0) or On (1) On (1)
RW Bit US
4.15.002 Reset Off (0) or On (1) Off (0)
RW Bit
4.15.003 Default Off (0) or On (1) Off (0)
RW Bit
4.15.004 Modbus Configuration Error
No error (0), Port in use (1),
Timeout event (2)
RO Txt
4.15.005 Modbus Listening Port 0 to 65535 502
RW Num
4.15.006 Maximum Connections 0 to 4 2
RW Num US
4.15.007 Maximum Priority Connections 0 to 4 1
RW Num US
4.15.008 Maximum Connections Per Client 1 to 4 2
RW Num US
4.15.009 Modbus Timeout 1 to 10000 ms 100 ms
RW Num US
4.15.010 Modbus Timeout Action Trip (0), No action (1) No action (1)
RW Txt US
4.15.011 Modbus Timeout Event Destination This slot (0), Slot 1 (1), Slot 2 (2), Slot 3 (3), Slot 4 (4) This slot (0)
RW Txt US
4.15.012 Modbus Timeout Event Type
No event (0), Trigger Event (1), Trigger Event 1 (2),
Trigger Event 2 (3), Trigger Event 3 (4),
Trigger Event 4 (5)
No event (0)
RW Txt US
4.15.013 Modbus Register Addressing Mode Standard (0), Modified (1) Standard (0)
RW Txt US
4.15.020 Priority Connection 1 0.0.0.0 to 255.255.255.255 0.0.0.0
RW IP US
4.15.021 Priority Connection 2 0.0.0.0 to 255.255.255.255 0.0.0.0
RW IP US
4.15.022 Priority Connection 3 0.0.0.0 to 255.255.255.255 0.0.0.0
RW IP US
4.15.023 Priority Connection 4 0.0.0.0 to 255.255.255.255 0.0.0.0
RW IP US
RW Read / Write RO Read only Num Number parameter Bit Bit parameter Txt Text string Bin Binary parameter FI Filtered
ND No default value NC Not copied PT Protected parameter RA Rating dependent US User save PS Power-down save DE Destination
IP IP address Mac Mac address Date Date parameter Time Time parameter SMP Slot,menu,parameter Chr Character parameter Ver Version number
