218 Unidrive M702 User Guide
Issue Number: 3
11.21.1 Slot 4 Menu 0: Ethernet status and monitoring
11.21.2 Slot 4 Menu 2: Ethernet configuration
Parameter
Range Default
Type
OL RFC-A RFC-S OL RFC-A RFC-S
24.001 Module ID 0 to 65535 RO Num ND NC PT
24.002 Software Version 00.00.00.00 to 99.99.99.99 RO Num ND NC PT
24.003 Hardware Version 0.00 to 99.99 RO Num ND NC PT
24.004 Serial Number LS 00000000 to 99999999 RO Num ND NC PT
24.005 Serial Number MS 0 to 99999999 RO Num ND NC PT
24.006 Status
Bootldr-Update (-2), Bootldr-Idle (-1),
Initializing (0), OK (1), Config (2), Error (3)
RO Txt ND NC PT
24.007 Reset Off (0) or On (1) Off (0) RW Bit NC
24.008 Default Off (0) or On (1) Off (0) RW Bit NC
24.009 Active Alarm Bits 0000000000000000 to 1111111111111111 0000000000000000 RO Bin NC
24.010 Active IP Address 128.0.0.0 to 127.255.255.255 0.0.0.0 RO IP NC PT
RW Read / Write RO Read only Num Number parameter Bit Bit parameter Txt Text string Bin Binary parameter FI Filtered
ND No default value NC Not copied PT Protected parameter RA Rating dependent US User save PS Power-down save DE Destination
IP IP address Mac Mac address Date Date parameter Time Time parameter SMP Slot,menu,parameter Chr Character parameter Ver Version number
Parameter
Range Default
Type
OL RFC-A RFC-S OL RFC-A RFC-S
4.02.003 Network Status
Initializing (0), Links Down (1),
DHCP In Progress (2), No Address (3),
Ready (4), Active (5)
RO Txt ND NC PT
4.02.004 Network Message Count 0 to 65535 RO Num ND NC PT
4.02.005 DHCP Enable Off (0) or On (1) On (1) RW Num US
4.02.006 IP Address 0.0.0.0 to 255.255.255.255 192.168.001.100 RW IP US
4.02.007 Subnet Mask 0.0.0.0 to 255.255.255.255 255.255.255.000 RW IP US
4.02.008 Default Gateway 0.0.0.0 to 255.255.255.255 192.168.1.254 RW IP US
4.02.009 Primary DNS 0.0.0.0 to 255.255.255.255 0.0.0.0 RW IP US
4.02.010 Secondary DNS 0.0.0.0 to 255.255.255.255 0.0.0.0 RW IP US
4.02.011 MAC Address 00:00:00:00:00:00 to FF:FF:FF:FF:FF:FF RO Mac ND NC PT
4.02.020 Priority Protocol None (0), Modbus TCP (1), EtherNet/IP (2) 0 RW Txt US
4.02.021 Web Server Enable Off (0) or On (1) On (1) RW Bit US
4.02.022 Web Server Port 0 to 65535 80 RW Num US
4.02.024 Ethernet MTU 158 to 1500 Bytes 1500 Bytes RW Num US
4.02.025 Gateway Mode
Switch (0), Gateway (1),
Strict Gateway (2)
Switch (0) RW Txt US
4.02.030 VLAN Enable Off (0) or On (1) Off (0) RW Bit US
4.02.031 VLAN ID 0 to 255 0 RW Num US
4.02.035 Non cyclic enable Off (0) or On (1) Off (0) RW Bit US
4.02.036 Non cyclic base parameter 0.00.000 to 0.59.999 0.00.000 RW SMP US
RW Read / Write RO Read only Num Number parameter Bit Bit parameter Txt Text string Bin Binary parameter FI Filtered
ND No default value NC Not copied PT Protected parameter RA Rating dependent US User save PS Power-down save DE Destination
IP IP address Mac Mac address Date Date parameter Time Time parameter SMP Slot,menu,parameter Chr Character parameter Ver Version number
