11.9 Menu 9: Programmable logic, motorized pot, binary sum and timers
Figure 11-20 Menu 9 logic diagram: Programmable logic
??.???
Any
unprotected
bit
parameter
??.???
09.010
Function-1
Destination
Parameter
??.???
Any bit
parameter
??.???
x(-1)
09.004
Function-1 Input-1
SourceParameter
09.005
Function-1
Input-1 Invert
??.???
Any bit
parameter
??.???
x(-1)
09.006
Function-1 Input-2
Source Parameter
09.007
Function-1
Input-2 Invert
09.008
Function-1
Output Invert
09.009
Function-1
Delay
x(-1)
Function-1
Output
Indicator
09.001
??.???
Any
unprotected
bit
parameter
??.???
09.020
Function-2
Destination
Parameter
??.???
Any bit
parameter
??.???
x(-1)
09.014
Function-2 Input-1
Source Parameter
09.015
Function-2
Input-1 Invert
??.???
Any bit
parameter
??.???
x(-1)
09.016
Function-2 Input-2
Source Parameter
09.017
Function-2
Input-2 Invert
09.018
Function-2
output Invert
09.019
Function-2
Delay
x(-1)
Function-2
Output
Indicator
09.002
mm.ppp
mm.ppp
Key
Read-write (RW)
parameter
Read-only (RO)
parameter
Input
terminals
Output
terminals
X
X
X
X
The parameters are all shown in their default settings
