Table 2-10 Additional options
2.9 Items supplied with the drive
The drive is supplied with a copy of the Getting Started Guide, a safety information booklet, and an accessory kit box including the items shown in
Table 2-11.
Table 2-11 Parts supplied with the drive
Type Option Name Further Details
Back-up
SD Card Adaptor
SD Card Adaptor
Allows the drive to use an SD card for drive back-up
SMARTCARD
SMARTCARD
Used for parameter back-up with the drive
Description Size 3 Size 4 Size 5 Size 6 Size 7 Size 8
Control connectors
x 1
Relay connector
x 1
24 V power supply
connector
x 1
Grounding bracket
x 1
Surface mounting
brackets
x 2 x 2 x 2 x 2 x 2 x 2
Grounding clamp
x 1 x 1 x 1
DC terminal cover
grommets
x 2
Terminal nuts
M6 x 11 M8 x 12 M10 x 12
Supply and motor
connector
x 1 x 1 x 1
Finger guard
grommets
x 3 x 2
