2. PLOTTER
2-17
2.10.8 Alarms list
When an alarm is violated, you can see the name of the offending alarm on the
[Alarms] list. The list stores both warning and system messages. Open the home
screen, then tap [Lists] followed by [Alarms]. Active alarms are flashing and have a red
vertical bar at the let margin. Tap an active alarm to acknowledge it and stop the flash-
ing. After the cause of an alarm is removed, the alarm message is moved to [HISTOR-
IC] section. Tap the close button to close the list.
2.11 Track
The track (or movement) of your ship is
plotted on the screen with position data
fed from the internal GPS navigator. Your
track lets you see how your ship has
moved over time.
The track is saved to the hard disk if track recording is activated. A line runs between
each track point. The hard disk stores a maximum of 30,000 track points.
Track can be shared with other NavNet TZtouch2 units via LAN. Data is shared auto-
matically; no operation is required.
Track is saved when the power is turned off. Unnecessary track can be deleted. Track
can also be used to create a route.
2.11.1 How to start, stop recording the track
Start recording
Open the slide-out menu or tap the boat icon, then turn [Track] on.
Stop recording
Method 1: Tap the track, then tap [Stop Track].
Method 2: Open the slide-out menu or tap the boat icon, then turn [Track] off.
2.11.2 How to show or hide the track display
Open the [Layers] menu and turn [Tracks] on or off.
Depth Alarm
Color on Status bar
Message
Date, time alarm generated
To Next Page
