GE T60 User Manual

GE Multilin T60 Transformer Protection System 5-27
5 SETTINGS 5.2 PRODUCT SETUP
5
5.2.4 COMMUNICATIONS
a) MAIN MENU
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS
b) SERIAL PORTS
The T60 is equipped with up to two independent serial communication ports. The faceplate RS232 port is intended for local
use and is fixed at 19200 baud and no parity. The rear COM2 port be used for either RS485 or RRTD communications.
 COMMUNICATIONS

 SERIAL PORTS

See page 5–27.
MESSAGE
 NETWORK

See page 5–31.
MESSAGE
 ROUTING

See page 5–33.
MESSAGE
 MODBUS PROTOCOL

See page 5–36.
MESSAGE
PROTOCOL:
DNP 3.0
Range: DNP 3.0, IEC 60870-5-104, IEC 60870-5-103
MESSAGE
 DNP PROTOCOL

See page 5–38.
MESSAGE
 DNP / IEC104
 POINT LISTS
See page 5–41.
MESSAGE
 IEC 61850 PROTOCOL

See page 5–42.
MESSAGE
 WEB SERVER
 HTTP PROTOCOL
See page 5–57.
MESSAGE
 TFTP PROTOCOL

See page 5–57.
MESSAGE
 IEC 60870-5-104
 PROTOCOL
See page 5–58.
MESSAGE
 EGD PROTOCOL

See page 5–59.
MESSAGE
 IEC103
 PROTOCOL
See page 5–61.
