IEC 61850-90-5 AGGREGATOR 1 CONFIGURATION
• PMU AGGREGATOR1: NAME: A user-defined visible string of characters (max. 56) to identify the source of the
stream. This value, concatenated with the Aggregator IDCode and Aggregator Class of Service, is mapped into the
IEC 61850 MSVID filed in the output stream.
• AGGREGATOR1: PHYSICAL PORT: This setting determines the physical ports through which the synchrophasor traf-
fic is transmitted. The range is 1, 2, 3.
• PMU AGGREGATOR1: UDP: This setting selects the UDP port number that is used by this dataset for network report-
ing. A default setting value for IEC 6150-90-5 is provided.
• PMU AGGREGATOR1: NUMBER OF ASDUs: This setting sets the number of Application Service Data Units
(ASDUs) from 1 through to 4.
m) CONTROL BLOCKS
PATH: SETTINGS  SYSTEM SETUP PHASOR MEASUREMENT UNIT IEC 90 – 5 MSVCB01 CONFIGURATION
as above AGTR2 PDC CNTRL 1 Phasor data concentrator asserts control bit 1 as
received via the network
as above AGTR2 PDC CNTRL 2 Phasor data concentrator asserts control bit 2 as
received via the network
as above AGTR2 PDC CNTRL 3 Phasor data concentrator asserts control bit 3 as
received via the network.

as above AGTR1 PDC CNTRL 16 Phasor data concentrator asserts control bit 16, as
received via the network.
Table 5–17: NUMBER OF ASDU
SETTINGS FOR ASDU TRANSMISSION
1 ASDU at T0 (current values)
2 ASDU at T-1 (previous values) + ASDU at T0 (current values)
3 ASDU at T-2 (previous values) + ASDU at T-1 (previous values) + ASDU at T0 (current values)
4 ASDU at T-3 (previous values) + ASDU at T-2 (previous values) + ASDU at T-1 (previous values) +
ASDU at T0 (current values)
 IEC 90-5 MSVCB
 CONFIGURATION
MSVCB 1 SVENA:
OFF
Range: FlexLogic operand
MESSAGE
MSVCB 1 CLIENT CTRL:
OFF
Range: FlexLogic operand
MESSAGE
MSVCB 1 SVENA DEFLT:
OFF
Range: FlexLogic operand
MESSAGE
MSVCB 1 CONFREV:
1
Range: 1 to 4294967295
MESSAGE
MSVCB 1 PRIORITY:
4
Range: 0 to 7
MESSAGE
MSVCB 1 IP CLASS:
46
Range: 0 to 252
MESSAGE
MSVCB 1 VID:
0
Range: 0 to 4095
MESSAGE
MSVCB 1 APPID:
0
Range: 0 to 16383
Table 5–16: FLEXLOGIC OPERANDS SUPPORTED BY AGGREGATOR
OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION
