GE T60 User Manual

H-2 T60 Transformer Protection System GE Multilin
H.1 CHANGE NOTES APPENDIX H
H
H.1.2 CHANGES TO THE T60 MANUAL
1601-0090-V1 5.8x 29 May 2010 09-1457
1601-0090-V2 5.8x 04 January 2011 11-2237
1601-0090-W1 5.9x 12 January 2011 11-2227
1601-0090-X1 6.0x 21 December 2011 11-2840
1601-0090-X2 6.0x 5 April 2012 12-3254
1601-0090-Y1 7.0x 30 September 2012 12-3529
1601-0090-Y2 7.0x 11 November 2012 12-3601
1601-0090-Z1 7.1x 30 March 2013 13-0126
1601-0090-AA1 7.2x 1 August 2013 13-0401
1601-0090-AA2 7.2x 31 December 2014 14-1732
Table H–1: MAJOR UPDATES FOR T60 MANUAL REVISION AA2
PAGE
(AA1)
PAGE
(AA2)
CHANGE DESCRIPTION
--- --- Update General revision throughout document
--- --- Update Updated references to digital inputs/outputs to contact inputs/outputs for consistency
5-23 5-23 Add Added Syslog Format section
5-31 5-31 Add Added Far-End Fault Indication (FEFI) section
B-58 B-58 Delete Deleted Permissive Overreach Transfer Trip (POTT) Settings from Modbus memory map table
(registers A070 through A07E)
B- B- Update Updated Modbus memory map and F codes
H-8 H-8 Update Updated product warranty from 24 months to 10 years
Table H–2: MAJOR UPDATES FOR T60 MANUAL REVISION AA1
PAGE
(Z1)
PAGE
(AA1)
CHANGE DESCRIPTION
--- --- Add Added frequency rate of change function to chapter 2 Specifications, chapter 5 Settings, chapter
6 Actual Values, Appendix A table, and Appendix B tables, as per F60 implementation
--- --- Add Added content for IEC 60870-5-103 throughout document
2- 2- Update Updated order codes
2-15 2-15 Delete Deleted software options 20, 21, 22, and 23 from process bus order code tables as per exception
30009
2- 2- Update Updated specifications
5-221 5-221 Update Updated Neutral Directional Overcurrent settings to include Dual-V and Dual-I settings to reflect
enhanced polarity criteria
6-21 6-21 Add Added Z
BASE
to Table 6-2 FlexElements Base Units
--- 6-25 Add Added Distance section for Actual Values > Metering > Distance
8- --- Delete Deleted chapter 8 on security, moving content to other chapters
--- 9- Add Added Maintenance chapter, moving content from other chapters and adding new instructions to
replace the battery
--- D- Add Added new appendix on IEC 60870-5-103 interoperability
