GE T60 User Manual

B-100 T60 Transformer Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F543
ENUMERATION: PMU PHASORS
F544
ENUMERATION: PMU RECORDING/REPORTING RATE
F546
ENUMERATION: PMU REPORTING STYLE
0 = Polar, 1 = Rectangular
F547
ENUMERATION: PMU REPORTING FORMAT
0 = Integer, 1 = Floating
F550
ENUMERATION: RTD INPUT APPLICATION
F551
ENUMERATION: RTD TRIP VOTING
F552
ENUMERATION: RTD INPUT OPEN
F563
ENUMERATION: DSCP TYPE
F600
UR_UINT16: FLEXANALOG PARAMETER
Corresponds to the Modbus address of the value used when this
parameter is selected. Only certain values may be used as Flex-
Analogs (basically all metering quantities used in protection).
F601
ENUMERATION: COM2 PORT USAGE
Value Phasor Value Phasor
0Off 8 Ig
1Va 9V_1
2Vb 10V_2
3Vc 11V_0
4Vx 12I_1
5Ia 13I_2
6Ib 14I_0
7Ic
Value Rate Value Rate
0 1/second 7 20second
1 2/second 8 25/second
2 4/second 9 30/second
3 5/second 10 50/second
4 10/second 11 60/second
5 12/second 12 100/second
6 15/second 13 120/second
Enumeration RTD input application
0None
1Stator
2 Bearing
3Ambient
4Group 1
5Group 2
Enumeration RTD trip voting
0None
1 Group
2 RTD Input 1
3 RTD Input 2
4 RTD Input 3
5 RTD Input 4
6 RTD Input 5
7 RTD Input 6
8 RTD Input 7
9 RTD Input 8
10 RTD Input 9
11 RTD Input 10
12 RTD Input 11
13 RTD Input 12
Enumeration RTD open
0None
1Alarm
2Block
Enumeration DSCP type
0None
1 Expedited Forwarding
Enumeration COM2 port usage
0 RS485
1RRTD
2 GPM-F
3 RRTD and GPM-F
