GE T60 User Manual

6-28 T60 Transformer Protection System GE Multilin
6.4 RECORDS 6 ACTUAL VALUES
6
6.4RECORDS 6.4.1
6.4.2 USER-PROGRAMMABLE FAULT REPORTS
PATH: ACTUAL VALUES  RECORDS  USER-PROGRAMMABLE FAULT REPORT
This menu displays the user-programmable fault report actual values. See the User-Programmable Fault Report section in
chapter 5 for additional information on this feature.
6.4.3 EVENT RECORDS
PATH: ACTUAL VALUES  RECORDS  EVENT RECORDS
The event records menu shows the contextual data associated with up to the last 1024 events, listed in chronological order
from most recent to oldest. If all 1024 event records have been filled, the oldest record will be removed as a new record is
added. Each event record shows the event identifier/sequence number, cause, and date/time stamp associated with the
event trigger. Refer to the
COMMANDS  CLEAR RECORDS menu for clearing event records.
6.4.4 OSCILLOGRAPHY
PATH: ACTUAL VALUES  RECORDS  OSCILLOGRAPHY
 USER-PROGRAMMABLE
 FAULT REPORT
NEWEST RECORD
NUMBER: 0
MESSAGE
LAST CLEARED DATE:
2002/8/11 14:23:57
MESSAGE
LAST REPORT DATE:
2002/10/09 08:25:27
 EVENT RECORDS

EVENT: XXXX
RESET OP(PUSHBUTTON)

MESSAGE
EVENT: 3
POWER ON
EVENT 3
DATE: 2000/07/14
MESSAGE
EVENT: 2
POWER OFF
EVENT 3
TIME: 14:53:00.03405
MESSAGE
EVENT: 1
EVENTS CLEARED
Date and Time Stamps
 OSCILLOGRAPHY

FORCE TRIGGER?
No
Range: No, Yes
MESSAGE
NUMBER OF TRIGGERS:
0
MESSAGE
AVAILABLE RECORDS:
0
MESSAGE
CYCLES PER RECORD:
0.0
MESSAGE
LAST CLEARED DATE:
2000/07/14 15:40:16
