C-26 T60 Transformer Protection System GE Multilin
C.7 LOGICAL NODES APPENDIX C
C
C.7LOGICAL NODES C.7.1 LOGICAL NODES TABLE
The UR-series of relays supports IEC 61850 logical nodes as indicated in the following table. Note that the actual instantia-
tion of each logical node is determined by the product order code. For example. the logical node “PDIS” (distance protec-
tion) is available only in the D60 Line Distance Relay.
Table C–1: IEC 61850 LOGICAL NODES (Sheet 1 of 4)
NODES UR-FAMILY
L: SYSTEM LOGICAL NODES
LPHD: Physical device information Yes
LLN0: Logical node zero Yes
LCCH: Physical communication channel supervision ---
LGOS: GOOSE subscription ---
LSVS: Sampled value subscription ---
LTIM: Time management ---
LTMS: Time master supervision ---
LTRK: Service tracking ---
A: LOGICAL NODES FOR AUTOMATIC CONTROL
ANCR: Neutral current regulator ---
ARCO: Reactive power control ---
ATCC: Automatic tap changer controller ---
AVCO: Voltage control ---
C: LOGICAL NODES FOR CONTROL
CALH: Alarm handling ---
CCGR: Cooling group control ---
CILO: Interlocking ---
CPOW: Point-on-wave switching ---
CSWI: Switch controller Yes
CSYN: Synchronizer controller ---
F: LOGICAL NODES FOR FUNCTIONAL BLOCKS
FCNT: Counter ---
FCSD: Curve shape description ---
FFIL: Generic filler ---
FLIM: Control function output limitation ---
FPID: PID regulator ---
FRMP: Ramp function ---
FSPT: Set-point control function ---
FXOT: Action at over threshold ---
FXUT: Action at under threshold ---
G: LOGICAL NODES FOR GENERIC REFERENCES
GAPC: Generic automatic process control ---
GGIO: Generic process I/O Yes
GLOG: Generic log ---
GSAL: Generic security application ---
I: LOGICAL NODES FOR INTERFACING AND ARCHIVING
IARC: Archiving ---
IHMI: Human machine interface ---
ISAF: Safety alarm function ---
ITCI: Telecontrol interface ---
ITMI: Telemonitoring interface ---
