GE T60 User Manual

GE Multilin T60 Transformer Protection System A-1
APPENDIX A A.1 PARAMETER LISTS
A
Appendices APPENDIX A FlexAnalog and FlexInteger Parameters A.1Parameter Lists A.1.1 FLEXANALOG ITEMS
FlexAnalog items are also viewable in a web browser. In the browser, enter the IP address of the UR, access the Device
Information Menu option, then the FlexAnalog Parameter Listing option.
Table A–1: FLEXANALOG DATA ITEMS (Sheet 1 of 25)
ADDRESS FLEXANALOG NAME UNITS DESCRIPTION
5792 RGF 1 Igd Mag Amps Restricted ground fault 1 differential ground current magnitude
5794 RGF 1 Igr Mag Amps Restricted ground fault 1 restricted ground current magnitude
5796 RGF 2 Igd Mag Amps Restricted ground fault 2 differential ground current magnitude
5798 RGF 2 Igr Mag Amps Restricted ground fault 2 restricted ground current magnitude
5800 RGF 3 Igd Mag Amps Restricted ground fault 3 differential ground current magnitude
5802 RGF 3 Igr Mag Amps Restricted ground fault 3 restricted ground current magnitude
5804 RGF 4 Igd Mag Amps Restricted ground fault 4 differential ground current magnitude
5806 RGF 4 Igr Mag Amps Restricted ground fault 4 restricted ground current magnitude
5808 RGF 5 Igd Mag Amps Restricted ground fault 5 differential ground current magnitude
5810 RGF 5 Igr Mag Amps Restricted ground fault 5 restricted ground current magnitude
5812 RGF 6 Igd Mag Amps Restricted ground fault 6 differential ground current magnitude
5814 RGF 6 Igr Mag Amps Restricted ground fault 6 restricted ground current magnitude
5824 Field RTD 1 Value --- Field RTD 1 value
5825 Field RTD 2 Value --- Field RTD 2 value
5826 Field RTD 3 Value --- Field RTD 3 value
5827 Field RTD 4 Value --- Field RTD 4 value
5828 Field RTD 5 Value --- Field RTD 5 value
5829 Field RTD 6 Value --- Field RTD 6 value
5830 Field RTD 7 Value --- Field RTD 7 value
5831 Field RTD 8 Value --- Field RTD 8 value
5832 Field TDR 1 Value --- Field TDR 1 value
5834 Field TDR 2 Value --- Field TDR 2 value
5836 Field TDR 3 Value --- Field TDR 3 value
5838 Field TDR 4 Value --- Field TDR 4 value
5840 Field TDR 5 Value --- Field TDR 5 value
5842 Field TDR 6 Value --- Field TDR 6 value
5844 Field TDR 7 Value --- Field TDR 7 value
5846 Field TDR 8 Value --- Field TDR 8 value
5856 Freq Rate 1 Value Hz/s Frequency rate of change 1 actual value
5860 Freq Rate 2 Value Hz/s Frequency rate of change 2 actual value
5864 Freq Rate 3 Value Hz/s Frequency rate of change 3 actual value
5868 Freq Rate 4 Value Hz/s Frequency rate of change 4 actual value
6144 SRC 1 Ia RMS Amps Source 1 phase A current RMS
6146 SRC 1 Ib RMS Amps Source 1 phase B current RMS
6148 SRC 1 Ic RMS Amps Source 1 phase C current RMS
6150 SRC 1 In RMS Amps Source 1 neutral current RMS
6152 SRC 1 Ia Mag Amps Source 1 phase A current magnitude
6154 SRC 1 Ia Angle Degrees Source 1 phase A current angle
6155 SRC 1 Ib Mag Amps Source 1 phase B current magnitude
6157 SRC 1 Ib Angle Degrees Source 1 phase B current angle
6158 SRC 1 Ic Mag Amps Source 1 phase C current magnitude
6160 SRC 1 Ic Angle Degrees Source 1 phase C current angle
