5 SETTINGS 5.4 SYSTEM SETUP
5
Figure 5–27: EXAMPLE USE OF SOURCES
5.4.4 TRANSFORMER
a) TRANSFORMER SETUP MAIN MENU
PATH: SETTINGS  SYSTEM SETUP  TRANSFORMER
Y LV D HV AUX
SRC 1 SRC 2 SRC 3
Phase CT M1 F1+F5 None
Ground CT M1 None None
Phase VT M5 None None
Aux VT None None U1
 TRANSFORMER

 GENERAL

See page 5–108.
MESSAGE
 WINDING 1

See page 5–110.
MESSAGE
 WINDING 2

See page 5–110.
MESSAGE
 WINDING 3

See page 5–110.
827794A1.CDR
F 5
F 1
DSP Bank
U 1
M 1
M 1
M 5
51BF-1 51BF-2
Source 4
87T
51P
UR Relay
A
V
V
A
W
W
Var
Var
Amps
Source 1
Source 3
Volts
Amps
Amps
Volts
Amps
Source 2
