GE Multilin T60 Transformer Protection System 5-93
5 SETTINGS 5.2 PRODUCT SETUP
5
Select the DIRECT I/O DATA RATE to match the data capabilities of the communications channel. All IEDs communicating
over direct inputs and outputs must be set to the same data rate. UR-series IEDs equipped with dual-channel communica-
tions cards apply the same data rate to both channels. Delivery time for direct input and output messages is approximately
0.2 of a power system cycle at 128 kbps and 0.4 of a power system cycle at 64 kbps, per each ‘bridge’.
The G.703 modules are fixed at 64 kbps. The
DIRECT I/O DATA RATE setting is not applicable to these modules.
Table 5–11: DIRECT INPUT AND OUTPUT DATA RATES
MODULE CHANNEL SUPPORTED DATA RATES
74 Channel 1 64 kbps
Channel 2 64 kbps
7L Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
7M Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
7P Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
7T Channel 1 64 kbps, 128 kbps
7W Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
7V Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
2A Channel 1 64 kbps
2B Channel 1 64 kbps
Channel 2 64 kbps
2G Channel 1 128 kbps
2H Channel 1 128 kbps
2I Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
2J Channel 1 64 kbps, 128 kbps
Channel 2 64 kbps, 128 kbps
76 Channel 1 64 kbps
77 Channel 1 64 kbps
Channel 2 64 kbps
75 Channel 1 64 kbps
Channel 2 64 kbps
7E Channel 1 64 kbps
Channel 2 64 kbps
7F Channel 1 64 kbps
Channel 2 64 kbps
7G Channel 1 64 kbps
Channel 2 64 kbps
7Q Channel 1 64 kbps
Channel 2 64 kbps
7R Channel 1 64 kbps
7S Channel 1 64 kbps
Channel 2 64 kbps
