6 ACTUAL VALUES 6.3 METERING
6
The daily rate loss of life is summarized at 00:00 h, and displayed for the next 24 hour period. The transformer accumulated
loss of life in hours is also available. It can be reset by either changing the XFMR INITIAL LOSS OF LIFE setting or through the
COMMANDS  CLEAR RECORDS  CLEAR LOSS OF LIFE RECORDS command.
6.3.3 SOURCES
a) MAIN MENU
PATH: ACTUAL VALUES  METERING  SOURCE SRC1(6)
This menu displays the metered values available for each source.
Metered values presented for each source depend on the phase and auxiliary VTs and phase and ground CTs assignments
for this particular source. For example, if no phase VT is assigned to this source, then any voltage, energy, and power val-
ues will be unavailable.
b) PHASE CURRENT METERING
PATH: ACTUAL VALUES  METERING  SOURCE SRC 1  PHASE CURRENT
 SOURCE SRC 1

 PHASE CURRENT
 SRC 1
See page 6–17.
MESSAGE
 GROUND CURRENT
 SRC 1
See page 6–18.
MESSAGE
 PHASE VOLTAGE
 SRC 1
See page 6–18.
MESSAGE
 AUXILIARY VOLTAGE
 SRC 1
See page 6–19.
MESSAGE
 POWER
 SRC 1
See page 6–19.
MESSAGE
 ENERGY
 SRC 1
See page 6–20.
MESSAGE
 DEMAND
 SRC 1
See page 6–20.
MESSAGE
 FREQUENCY
 SRC 1
See page 6–21.
MESSAGE
 CURRENT HARMONICS
 SRC 1
See page 6–22.
 PHASE CURRENT
 SRC 1
SRC 1 RMS Ia: 0.000
b: 0.000 c: 0.000 A
MESSAGE
SRC 1 RMS Ia:
0.000 A
MESSAGE
SRC 1 RMS Ib:
0.000 A
MESSAGE
SRC 1 RMS Ic:
0.000 A
MESSAGE
SRC 1 RMS In:
0.000 A
MESSAGE
SRC 1 PHASOR Ia:
0.000 A 0.0°
MESSAGE
SRC 1 PHASOR Ib:
0.000 A 0.0°
