1.3 Scre
en Confi
gurati
on and D
isplay
24
1.3
Screen Configuration and Display
Monitor Screen
Y
ou can check the in-
put state (p. 55).
PRESETS Screen (Setting Wizard)
Allows you to configure
the settings by follow-
ing instructions dis-
played on
the screen
(p. 63).
33
35
