4.3 Using High-speed Function (Instantaneous Recording)
76
Auto Range can only be set when the High-speed Function is used.
When you do not know how to determine the range for the input signal, you can set
the range automatically (Auto Range) on the Waveform screen or [CH] screen or in
Setting Wizard (using the PRESETS key).
Furthermore, the instrument can be set by loading setting configuration data saved
to the instrument or a CF card (when inserted).
(p. 157)
Configuring Settings Automatically (Auto Range)
Select [Auto Range].
1
3
Press and hold together
for one second.
A dialog appears.
Select the Waveform
Screen.
(Simultaneously)
When [Auto Range failed] appears.
If the voltage level of the input signal is
low, it may not be possible to determine
a suitable range. In this case, configure
the range settings manually from the
Setting screen while watching the wave-
form monitor.
Apply
Auto Range from the Waveform Screen
2
Select [Zero adj.].
1
2
A dialog appears.
If you follow the instructions in the dialog box, the
range will be set to match the input waveform.
Selecting Auto Range on the Setting Screen
(Also Settable in Setting Wizard using the PRESETS key)
Apply
3
Apply
Select [Auto Range].
Bottom right of
screen
Select the [All CH] screen.
