Parameter Name / value range / [default seng] Info
0x2946:004
(P340.04)
Speed limitaon: Lower speed limit source
(Speed limitaon: Lowspeed lim src)
•
From version 03.00
Selecon of the source for the lower speed limit.
0 (-) Maximum frequency Lower speed limit = (-) Maximum frequency 0x2916 (P211.00).
1 Fixed Limit 0.0 Hz Lower speed limit = 0.0 Hz.
2 Analog input 1 The lower speed limit is dened as analog signal via the analog input 1.
4Analog input 1 ^ 597
3 Analog input 2 The lower speed limit is dened as analog signal via the analog input 2.
4Analog input 2 ^ 601
4 Lower frequency limit Lower speed limit = seng in 0x2946:006 (P340.06) in [Hz].
5 Lower speed limit Lower speed limit = seng in 0x2946:002 (P340.02) in [vel. unit].
6 Network target velocity The lower speed limit is dened as process data object via network.
4Conguring the network ^ 226
0x2946:005
(P340.05)
Speed limitaon: Upper frequency limit
(Speed limitaon: Upper freq.limit)
Device for 50-Hz mains: -1000.0 ... [50.0] ... 1000.0 Hz
Device for 60-Hz mains: -1000.0 ... [60.0] ... 1000.0 Hz
•
From version 03.00
Upper limit for the speed limitaon.
•
Seng is only eecve with the selecon "Lower frequency limit [4]"
in 0x2946:004 (P340.04).
0x2946:006
(P340.06)
Speed limitaon: Lower frequency limit
(Speed limitaon: Lower freq.limit)
Device for 50-Hz mains: -1000.0 ... [-50.0] ...
1000.0 Hz
Device for 60-Hz mains: -1000.0 ... [-60.0] ...
1000.0 Hz
•
From version 03.00
Lower limit for speed limitaon.
•
Seng is only eecve with the selecon "Lower frequency limit [4]"
in 0x2946:004 (P340.04).
0x2946:007
(P340.07)
Speed limitaon: Actual upper speed limit
(Speed limitaon: Act uppspeed lim)
•
Read only: x.x Hz
•
From version 03.00
Display of the current upper limit for speed limitaon.
0x2946:008
(P340.08)
Speed limitaon: Actual lower speed limit
(Speed limitaon: Act lowspeed lim)
•
Read only: x.x Hz
•
From version 03.00
Display of the current lower limit for speed limitaon.
0x2948:002
(P336.02)
ramp me
(Ramp me)
0.0 ... [1.0] ... 60.0 s
•
From version 03.00
Ramp me for operang mode "MS: Torque mode".
•
The torque setpoint is led via a ramp generator. This provides for a
"smooth" switch-over between dierent setpoint sources.
•
The set ramp me refers to the ramping up/down of 0 ... 100 % rated
motor torque 0x6076 (P325.00). At a lower setpoint selecon, the
ramp me is reduced accordingly.
0x2949:001
(P337.01)
Posive torque limit source
(Pos. torqlim src)
•
From version 03.00
Selecon of the source for the posive torque limit source.
0 Max torque Posive torque limit source = Max torque 0x6072 (P326.00).
1 Fixed Limit 0.0 % Posive torque limit source = 0.0 %.
2 Analog Input 1 The posive torque limit source is dened as analog signal via the analog
input 1.
4Analog input 1 ^ 597
3 Analog Input 2 The posive torque limit source is dened as analog signal via the analog
input 2.
4Analog input 2 ^ 601
4 Posive torque limit Posive torque limit source = Posive torque limit 0x60E0.
5 Network target torque The posive torque limit source is dened as process data object via net-
work.
4Conguring the network ^ 226
Motor control
Opmisaon of the control loops
Motor controller sengs
209
