Parameter Name / value range / [default seng] Info
0x4045:001 ...
0x4045:032
(P754.01 ... 32)
Parameter value set 4: Value of parameter 1 ... Value
of parameter 32
(Par. value set 4: Set 4 - Value 1 ... Set 4 - Value 32)
-2147483648 ... [0] ... 2147483647
Value set 4 for the parameter list dened in 0x4041:001 ... 0x4041:032
(P750.01 ... 32).
0x4046
(P755.00)
Acvaon of parameter set
(PSet acvaon)
Selecon of the acvaon method for the parameter change-over.
•
If the selecon is changed from "Via command... [0]/[1]" to "If the
selecon is changed...[2]/[3]" aer switch-on, the parameter set
selected via the funcons "Select parameter set (bit 0)" and "Select
parameter set (bit 1)" is acvated immediately. In case of selecon
[2], however, this only takes place if the inverter is disabled, the motor
is stopped or an error is acve.
0 Via command (disable required) The parameter set selected via the funcons "Select parameter set (bit
0)" and "Select parameter set (bit 1)" is acvated if the trigger assigned
to the "Load parameter set" funcon in 0x2631:040 (P400.40) provides a
FALSE-TRUE edge AND the inverter is inhibited, the motor is stopped or
an error is acve.
1 Via command (immediately) The parameter set selected via the funcons "Select parameter set (bit
0)" and "Select parameter set (bit 1)" is immediately acvated if the trig-
ger assigned to the "Load parameter set" funcon in 0x2631:040
(P400.40) provides a FALSE-TRUE edge.
2 If the selecon is changed (disable required) The parameter set selected via the funcons "Select parameter set (bit
0)" and "Select parameter set (bit 1)" is acvated if the state of these
selecon bits changes AND the inverter is inhibited, the motor is stop-
ped or an error is acve.
3 If the selecon is changed (immediately) The parameter set selected via the funcons "Select parameter set (bit
0)" and "Select parameter set (bit 1)" is acvated immediately if the
state of these selecon bits is changed.
0x4047:001
(P756.01)
Parameter change-over error message: Status
(PSet error msg.: Status)
•
Read only
Error message for the "parameter change-over" funcon.
•
In the event of an error, an error status is shown here, and in
0x4047:002 (P756.02) the number of the list entry in which the error
has occurred is displayed (in connecon with the value set selected).
•
If several errors occur at the same me, only the rst incorrect list
entry will be displayed. Hence, aer eliminaon of the displayed error
and repeated acvaon, more errors may be displayed.
•
The parameter list will always be processed from beginning to end,
even if errors occur in the meanme.
0 No fault
33803 Invalid data type
33804 Range violaon
33806 Invalid index
33813 No element selected
33815 Wring impermissible
33816 Device not inhibited
33829 Invalid subindex
33837 Access impermissible
33860 Parameter not mappable
33865 No subindexes
33876 Parameter not changeable
0x4047:002
(P756.02)
Parameter change-over error message: List entry
(PSet error msg.: List entry)
•
Read only
Error message for the "Parameter set changeover" funcon.
•
In the event of an error, the number of the list entry for which the
error displayed in 0x4047:001 (P756.01) has occurred is shown here.
0x2631:040
(P400.40)
Funcon list: Load parameter set
(Funcon list: Load param.set)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 532
Assignment of a trigger for the "Load parameter set" funcon.
Trigger = FALSE-TRUE edge: parameter change-over to the value set
selected via "Select parameter set (bit 0)" and "Select parameter set (bit
1)".
Trigger = FALSE: no acon.
Notes:
•
The acvaon method for the "Parameter change-over" funcon can
be selected in 0x4046 (P755.00).
0 Not connected
0x2631:041
(P400.41)
Funcon list: Select parameter set (bit 0)
(Funcon list: Sel. paramset b0)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 532
Assignment of a trigger for the "Select parameter set (bit 0)" funcon.
Selecon bit with the valency 2
0
for "Parameter change-over" funcon.
Trigger = FALSE: selecon bit = "0".
Trigger = TRUE: selecon bit = "1".
0 Not connected
Addional funcons
Parameter change-over
465
