Congure the digital output 1 as pulse train output
In the default seng 0x2644:003 (P423.03) = "Not connected [0]", the digital output 1 is con-
gured as a "normal" digital output: The digital output 1 is controlled with the trigger selected
in 0x2634:002 (P420.02).
In order to congure the digital output 1 as pulse train output, the desired signal to be output
as pulse train must be selected in 0x2644:003 (P423.03). The trigger assigned to the digital
output 1 in 0x2634:002 (P420.02) is then not eecve anymore.
The following sengs are possible for the pulse train output:
•
Denion of the signal range
①
•
Denion of the output range
②
DO1
0x2644:0010x2644:004
0x2644:005
X3
0x2646:001
Hz
0x2644:003
[Hz]
Min
Max
0x2644:002
Signal
Diagnosc parameters:
•
The current frequency of the pulse train signal is displayed in 0x2646:001 (P114.01).
Denion of the signal range
The signal range results from the resoluon of the selected signal mulplied by the set min
and max signal value. Signals outside the signal range are cut o. For examples, see the fol-
lowing table:
Signal
0x2644:003 (P423.03)
Resoluon Minimum signal
0x2644:004 (P423.04)
Maximum signal
0x2644:005 (P423.05)
Signal range
Output frequency 0.1 Hz 0 1000 0 ... 100.0 Hz
Frequency setpoint 0.1 Hz 0 1000 0 ... 100.0 Hz
Analog input 1 0.1 % 0 1000 0 ... 100.0 %
Analog input 2 0.1 % 0 1000 0 ... 100.0 %
Motor current 0.1 A 0 100 0 ... 10.0 A
Output power 0.001 kW 0 250 0 ... 0.250 kW
Torque actual value 0.1 % * 0 1000 0 ... 100.0 % *
NetWordIN3 0.1 % 200 500 20.0 ... 50.0 %
NetWordIN4 0.1 % 0 250 0 ... 25.0 %
* 100 % ≡ Motor rated torque 0x6076 (P325.00)
Detailed conguraon examples can be found in the following subchapters.
Denion of the output range
The frequency output range dened in 0x2644:001 (P423.01) and 0x2644:002 (P423.02) cor-
responds to the congured signal range.
Conguraon examples
Detailed conguraon examples can be found in the following subchapters:
4Example 1: Pulse train 0 ... 10 kHz ≡ output frequency 0 ... 100 Hz ^ 615
4Example 2: Pulse train 2 ... 10 kHz ≡ output frequency 30 ... 60 Hz ^ 616
Parameter Name / value range / [default seng] Info
0x2644:001
(P423.01)
DO1 frequency setup: Minimum frequency
(DO1 freq. setup: Min. frequency)
0.0 ... [0.0] ... 10000.0 Hz
•
From version 05.00
Denion of the frequency output range.
0x2644:002
(P423.02)
DO1 frequency setup: Maximum frequency
(DO1 freq. setup: Max. frequency)
0.0 ... [10000.0] ... 10000.0 Hz
•
From version 05.00
Flexible I/O conguraon
Conguraon of digital outputs
HTL output
613
