Parameter Name / value range / [default seng] Info
0x2644:003
(P423.03)
DO1 frequency setup: Funcon
(DO1 freq. setup: Funcon)
•
From version 05.00
Selecon of the signal to be provided at the digital output 1 as pulse
train.
0 Not connected No pulse train signal is output at the digital output 1.
•
The digital output 1 is congured as "normal" digital output.
•
The digital output 1 is controlled with the trigger selected in
0x2634:002 (P420.02).
4Digital output 1 ^ 607
1 Output frequency Actual output frequency (resoluon: 0.1 Hz).
2 Frequency setpoint Actual frequency setpoint (resoluon: 0.1 Hz).
3 Analog input 1 Input signal of analog input 1 (resoluon: 0.1 %).
4 Analog input 2 Input signal of analog input 2 (resoluon: 0.1 %).
5 Motor current Actual motor current (resoluon: 0.1 A).
6 Output power Actual output power (resoluon: 0.001 kW).
7 Actual torque Torque actual value (resoluon: 0.1 %).
•
100 % ≡ permissible maximum torque 0x6072 (P326.00)
20 NetWordIN3 Actual value of the NetWordIN3 data word (resoluon: 0.1 %).
4Further process data ^ 251
21 NetWordIN4 Actual value of the NetWordIN4 data word (resoluon: 0.1 %).
4Further process data ^ 251
0x2644:004
(P423.04)
DO1 frequency setup: Minimum signal
(DO1 freq. setup: Min. signal)
-2147483648 ... [0] ... 2147483647
•
From version 05.00
Denion of the signal value that corresponds to the Minimum fre-
quency at the digital output 1.
0x2644:005
(P423.05)
DO1 frequency setup: Maximum signal
(DO1 freq. setup: Max. signal)
-2147483648 ... [1000] ... 2147483647
•
From version 05.00
Denion of the signal value that corresponds to the maximum fre-
quency at the digital output 1.
0x2645:001
(P424.01)
DO2 frequency setup: Minimum frequency
(DO2 freq. setup: Min. frequency)
0.0 ... [0.0] ... 10000.0 Hz
Parameter not available.
0x2645:002
(P424.02)
DO2 frequency setup: Maximum frequency
(DO2 freq. setup: Max. frequency)
0.0 ... [10000.0] ... 10000.0 Hz
0x2645:003
(P424.03)
DO2 frequency setup: Funcon
(DO2 freq. setup: Funcon)
0 Not connected
1 Output frequency
2 Frequency setpoint
3 Analog input 1
4 Analog input 2
5 Motor current
6 Output power
7 Actual torque
20 NetWordIN3
21 NetWordIN4
0x2645:004
(P424.04)
DO2 frequency setup: Minimum signal
(DO2 freq. setup: Min. signal)
-2147483648 ... [0] ... 2147483647
0x2645:005
(P424.05)
DO2 frequency setup: Maximum signal
(DO2 freq. setup: Max. signal)
-2147483648 ... [1000] ... 2147483647
0x2646:001
(P114.01)
DO actual frequency: Digital output 1
(DO actual freq.: Digital output 1)
•
Read only: x.x Hz
•
From version 05.00
Display of the current frequency of the pulse train signal at the digital
output 1.
0x2646:002
(P114.02)
DO actual frequency: Digital output 2
(DO actual freq.: Digital output 2)
•
Read only: x.x Hz
Parameter not available.
Flexible I/O conguraon
Conguraon of digital outputs
HTL output
614
