Mitsubishi FX3G Series User Manual

8 Installation In Enclosure
8.5 Procedures for Installing Directly (with M4 Screws)
94
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
4. Input/output extension block (E or F)
Unit: mm (inches)
5. Special function unit/block (G, H or I)
Unit: mm (inches)
8.5.2 Example of mounting hole pitches
Model name Mounting hole pitch(W)
E
FX2N-8ER-ES/UL
FX2N-8ER
FX2N-8EX-ES/UL
FX2N-8EX
FX2N-8EX-UA1/UL
FX2N-8EYR-ES/UL
FX2N-8EYT-ESS/UL
FX2N-8EYR
FX2N-8EYT
FX2N-8EYT-H
39 (1.54")
F
FX2N-16EX-ES/UL
FX2N-16EX
FX2N-16EX-C
FX2N-16EXL-C
FX2N-16EYR-ES/UL
FX2N-16EYR
FX2N-16EYT-ESS/UL
FX2N-16EYT
FX2N-16EYT-C
FX2N-16EYS
Refer to the figure shown
left.
Model name Mounting hole pitch(W)
G
FX2N-2AD
FX2N-2DA
FX2N-64CL-M
FX2N-32CCL
39 (1.54")
FX3U-4AD
FX3U-4DA
FX2N-4AD
FX2N-4DA
FX2N-4AD-PT
FX2N-4AD-TC
FX2N-5A
FX2N-2LC
FX3U-64CCL
FX3U-1PSU-5V
51 (2.01")
H FX2N-16CCL-M
Refer to the figure shown
left.
I
FX
2N-20PSU 52 (2.05")
FX
2N-8AD 67 (2.64")
4
(0.16")
W
80 (3.15")
E
90 (3.55")
F
20
(0.87")
20
(0.87")
80 (3.15") 90 (3.55")
4
(0.16")
W
80 (3.15")
G
90 (3.55")
H
75(2.96")
4
(0.16")
4
(0.16")
80 (3.15")
90 (3.55")
I
98 (3.86")
4
(0.16")
4
(0.16")
W
105 (4.14")
2 *
(0.08")
2 *
(0.08")
Unit:mm (inches)
* The gap between products is 2 mm (0.08").
B
122 (4.81")
FG
26
(1.03")
26
(1.03")
46
(1.82")
15.1
(0.6")
A
FX 2N -64CL-MFX 2N -16EXFX 3U -232ADP
(-MB)
FX 3G -40MT/ES
172 (6.78")
98 (3.86")
80 (3.15")
FX 2N -48ER
C
18.6
(0.74")
FX
3G
-CNV-ADP
2 * (0.08")
