9 Preparation for Wiring and Power Supply Wiring
9.2 Cable Connecting Procedures
108
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
9.2.2 Input/output connectors (FX2N input/output extension blocks)
The input/output connectors of FX2N Series input/output extension blocks (connector type) conform to MIL-C-
83503.
Prepare the input/output cables, referring to the following tables.
1. Applicable products
2. Preparation of input/output connectors
1) Compliant connectors (commercially available connectors)
Use 20-pin (1-key) sockets conforming to MIL-C-83503.
In advance, make sure that no interference is caused with peripheral parts, such as the connector cover.
2) Input/output cables (our options)
Input/output cables with attached connectors are available.
3) Connectors for making input/output cables by users (our options)
The users should prepare the electric wires and pressure bonding tool.
4) Certified connectors (commercially available connectors)
Connectors made by DDK Ltd. shown in Item (3) described in the previous page and connectors made by
Matsushita Electric Works, Ltd. shown in the following table
Classification Model names
Input/output extension blocks FX2N-16EX-C, FX2N-16EXL-C, FX2N-16EYT-C
Model names Length Description Shape
FX-16E-500CAB-S 5m(10’4") General-purpose input/output cable
• Single wire (Wire color: red)
• PLC side: A 20-pin connector
FX-16E-150CAB 1.5m(4’11")
Cables for connecting FX Series terminal block
and input/output connector
For the connection with FX Series terminal block,
refer to the following chapter.
→ [20. Terminal Block]
• Flat cables (with tube)
• A 20-pin connector at both ends
FX-16E-300CAB 3m(9’10")
FX-16E-500CAB 5m(10’4")
FX-16E-150CAB-R 1.5m(4’11")
• Round multicore cables
• A 20-pin connector at both ends
FX-16E-300CAB-R 3m(9’10")
FX-16E-500CAB-R 5m(10’4")
FX-A32E-150CAB 1.5m(4’11")
Cables for connecting A Series Model A6TBXY36
connector/terminal block conversion unit and
input/output connector type
• Flat cables (with tube)
• PLC side: Two 20-pin connectors in 16-
point units.
• Terminal block side: A dedicated
connector
• One common terminal covers 32 input/
output terminals.
FX-A32E-300CAB 3m(9’10")
FX-A32E-500CAB 5m(10’4")
Model name and composition of input/output connector
Applicable electric wire (UL-1061 are
recommended) and tool
Our model name
Details of part
(made by DDK Ltd.)
Electric wire size
Pressure bonding tool
(made by DDK Ltd.)
FX
2C-I/O-CON for flat cable
10-piece
set
Solderless connector FRC2-A020-30S
AWG28 (0.1mm
2
),
1.27 pitch, 20-core
357J-4674D: Main body
357J-4664N: Attachment
FX2C-I/O-CON-S for bulk wire
5-piece
set
Housing HU-200S2-001
Solderless contact HU-411S
AWG22 (0.3mm
2
)
357J-5538
FX2C-I/O-CON-SA for bulk wire
5-piece
set
Housing HU-200S2-001
Solderless contact HU-411SA
AWG20 (0.5mm
2
)
357J-13963
Model name of connector
Compliant electric wires
(UL-1061 is recommended)
Pressure bonding
tool
Housing AXW1204A
AWG22 (0.3mm
2
)
AWG24 (0.2mm
2
)
AXY52000Contact AXW7221
Semi-cover AXW62001A
To Next Page
