21.5 Saved Data Content
21.5 Saved Data Content
The following data is saved on the memory cassette.
*1. The maximum number of points for the memory capacity, comments, and file registers, can be
specified when the FX
3G programming tool is selected. The maximum number of points cannot be
specified when a programming tool other than the FX
3G is selected.
Item Description Saving Method
Program
Memory
Parameters
• Memory capacity setting
- Memory capacity (default setting: 8k steps)
2k/4k/8k/16k/32k steps
- Comment capacity
- File register capacity
• Modem initializing settings, Battery mode settings, RUN terminal settings
• RS/RS2 instructions / computer link function communication settings
• Positioning settings
Programming tool
*1
Sequence programs User-created sequence programs
Comments and file registers can be
created in the memory by setting
them in the parameter memory
capacity.
Comments
Max. 3150 points
(0 to 63 blocks,
1 block = 50 points / 500 steps)
File registers
Max. 7000 points
(0 to 14 blocks,
1 block = 500 points / 500 steps)
Extended file registers ER0 to ER23999 (24000 points)
• Sequence program
•GX Developer
