18.5.2 FX2N-CNV-BC

External Dimensions

• MASS(Weight): 40g (0.09lbs)

• Installation: Screws only

18.6 Interface Module

18.6.1 FX-232AWC-H

External Dimensions

• MASS(Weight): 0.1kg (0.22lbs)

• Accessories: Manual supplied with product

• Connector: RS-232C

(D-SUB 25-pin, female)

RS-422

(D-SUB 25-pin, female)

60.5(2.39")

30(1.19")

40(1.58")

Unit:mm (inches)

16.4

(0.65")

2- 3.2

mounting holes

Unit:mm (inches)

(0.99")

80(3.15")

60(2.37")
