19 Display Module(FX3G-5DM)
19.8 LANGUAGE (Menu Display Language Setting)
284
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
4) Use the [+] / [-] buttons to move the cursor to Japanese.
To cancel the operation and return to the "menu screen", press [ESC].
5) Press [OK] to register the selected display language and return to the "menu screen".
19.8.2 Changing to English menus
Refer to 19.8.1 Changing to Japanese menus for the access procedure from the title screen.
1) At the menu screen, use the [+] / [-] buttons to move the cursor to
the "LANGUAGE" item, then press [OK] to display the "display
language selection screen".
To cancel the operation and return to the "top screen (time
display)", press [ESC].
2) Use the [+] / [-] buttons to move the cursor to "English".
To cancel the operation and return to the "menu screen", press [ESC].
3) Press [OK] to register the selected display language and return to the "menu screen".
19.8.3 D8302 changes by program and related devices
Selections made at this menu are saved at D8302. A Language setting of "1" is specified at factory default.
D8302 changes by user program can also be specified.
*1. Latch device
Button Operation Description
ESC Cancels the operation and returns to the "menu screen".
- Moves the cursor upward.
+ Moves the cursor downward.
OK Registers the selected display language and returns to the "menu screen".
Button Operation Description
ESC Cancels the operation and returns to the "menu screen".
- Moves the cursor upward.
+ Moves the cursor downward.
OK
Registers the selected display language and returns to the "menu
screen".
D8302
*1
Current Value
Display Language
K0 Japanese
K1 English
Other English
LGNAUGAE
nEg ilsh
aJpnasee
MOV K0 D8302
M8002
When the display language is set to "Japanese"
