1 Introduction
1.2 Generic Names and Abbreviations Used in Manuals
21
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
1
Introduction
2
Features and
Part Names
3
Product
Introduction
4
Specifications
5
Version and
Peripheral
Devices
6
System
Configuration
7
Input/Output
Nos., Unit Nos.
8
Installation
9
Preparation and
Power Supply
Wiring
10
Input Wiring
1.2 Generic Names and Abbreviations Used in Manuals
Abbreviation/
generic name
Description
PLCs
FX3G Series Generic name for FX3G Series PLCs
FX3U Series Generic name for FX3U Series PLCs
FX2N Series Generic name for FX2N Series PLCs
FX3G PLCs or main units Abbreviation of FX3G Series PLC main units
Expansion boards
Generic name for the following models
FX3G-232-BD, FX3G-422-BD, FX3G-485-BD, FX3G-2AD-BD, FX3G-1DA-BD, FX3G-8AV-BD
Special adapters Generic name for communication special adapters and analog special adapters
Communication special
adapters
Generic name for the following models
FX3U-232ADP(-MB), FX3U-485ADP(-MB)
Analog special adapters
Generic name for the following models
FX3U-4AD-ADP, FX3U-4DA-ADP, FX3U-4AD-PT-ADP, FX3U-4AD-PTW-ADP,
FX3U-4AD-PNK-ADP, FX3U-4AD-TC-ADP
Extension devices Generic name for FX3U Series special function blocks, FX2N Series extension devices
FX2N Series extension devices
Generic name for FX2N Series input/output powered extension units, FX2N Series input/output
extension blocks and FX2N Series special function blocks
Input/output extension devices
Generic name for FX2N Series input/output powered extension units, FX2N Series input/output
extension blocks
FX2N Series input/output
powered extension units
Generic name for the following models
FX2N-32ER-ES/UL, FX2N-32ER, FX2N-32ES, FX2N-32ET-ESS/UL, FX2N-32ET, FX2N-48ER,
FX2N-48ER-ES/UL, FX2N-48ET, FX2N-48ET-ESS/UL, FX2N-48ER-UA1/UL
FX2N Series input/output
extension blocks
Generic name for the following models
FX2N-8ER-ES/UL, FX2N-8ER
FX2N Series input extension
blocks
Generic name for the following models
FX2N-16EX-ES/UL, FX2N-16EX, FX2N-16EX-C, FX2N-16EXL-C, FX2N-8EX-ES/UL,
FX2N-8EX-UA1/UL, FX2N-8EX
FX2N Series output extension
blocks
Generic name for the following models
FX2N-16EYR-ES/UL, FX2N-16EYR, FX2N-16EYT-ESS/UL, FX2N-16EYT, FX2N-16EYS,
FX2N-16EYT-C, FX2N-8EYR-ES/UL, FX2N-8EYT-ESS/UL, FX2N-8EYR, FX2N-8EYT, FX2N-8EYT-H
Special function blocks Generic name for FX3U Series special function blocks, FX2N Series special function blocks
FX3U Series special function
blocks
Generic name for the following models
FX3U-64CCL, FX3U-4AD, FX3U-4DA
FX
2N Series special function
units
Generic name for the following models
FX
2N-16CCL-M, FX2N-32CCL, FX2N-64CL-M, FX2N-2AD, FX2N-4AD, FX2N-8AD, FX2N-4AD-PT,
FX2N-4AD-TC, FX2N-2LC, FX2N-2DA, FX2N-4DA, FX2N-5A
Memory cassettes
Generic name for the following models
FX3G-EEPROM-32L
Display module
Generic name for the following models
FX3G-5DM
Battery Abbreviation of model FX3U-32BL battery
FX Series terminal blocks
Generic name for the following models
FX-16E-TB, FX-32E-TB, FX-16EX-A1-TB, FX-16EYR-TB, FX-16EYS-TB, FX-16EYT-TB,
FX-16EYT-H-TB
Extension cables
Generic name for the following models
FX0N-30EC, FX0N-65EC
Input/output cables
Generic name for the following models
FX-16E-500CAB-S, FX-16E CAB, FX-16E- CAB-R, FX-A32E- CAB
150, 300 or 500 is entered in .
Connectors for input/output
Generic name for the following models
FX2C-I/O-CON, FX2C-I/O-CON-S, FX2C-I/O-CON-SA
CC-Link master Abbreviation of FX2N-16CCL-M
Remote device stations Abbreviation of FX2N-32CCL
Intelligent device stations Abbreviation of FX3U-64CCL
Peripheral devices Generic name for programming software, handy programming panel (HPP) and indicator
Programming tool Generic name for programming software and handy programming panel (HPP)
Programming software Generic name for GX Developer and FX-PCS/WIN (-E)
GX Developer
Abbreviation of programming software packages SW D5C-GPPW-J and SW D5C-GPPW-E
FX-PCS/WIN (-E) Abbreviation of model FX-PCS/WIN and FX-PCS/WIN-E programming software packages
