19.9 Contrast
The liquid crystal display contrast setting is specified at the "Contrast" menu. Selections made at this menu
are saved at D8302. A contrast setting of "0" is specified at factory default.
1) At the menu screen, use the [+] / [-] buttons to move the cursor to
the "Contrast" item, then press [OK] to display the "contrast
adjustment screen".
To cancel the operation and return to the "top screen (time
display)", press [ESC].
2) Use the [+] / [-] buttons to adjust the contrast.
To cancel the operation and return to the "menu screen", press
[ESC].
3) Press the [OK] button to register the selected setting and return to the "menu screen".
Button Operation Description
ESC Cancels the operation and returns to the "menu screen".
-
Lowers the contrast
(decreases the numeric value. The value can be decreased to -5.)
+
Increases the contrast
(increases the numeric value. The value can be increased to +10.)
OK Registers the selected setting and returns to the "menu screen".
0
Ctnorast
(5-10)~
3
Ctnorast
(5-10)~
