3.1.4 Special function blocks
For details of each product, refer to the product manual.
1) Analog control
2) Data link functions
3.1.5 Display module
3.1.6 Expansion boards
3.1.7 Connector conversion adapter
Model name
Analog
Description
Input Output
Analog input
FX3U-4AD 4ch - Voltage/current input
FX2N-2AD 2ch - Voltage/current input
FX2N-4AD 4ch - Voltage/current input
FX2N-8AD 8ch - Voltage/current/temperature (thermocouple) input
FX2N-4AD-PT 4ch - Platinum resistance thermometer sensor input
FX2N-4AD-TC 4ch - Temperature (thermocouple) input
Analog output
FX3U-4DA - 4ch Voltage/current output
FX2N-2DA - 2ch Voltage/current output
FX2N-4DA - 4ch Voltage/current output
Analog input/output mixed
FX2N-5A 4ch 1ch Voltage/current input/output
Temperature control
FX2N-2LC 2 loops - Temperature control (resistance thermometer sensor/thermocouple)
Model name Description
FX2N-16CCL-M
Master for CC-Link
Connectable stations: Remote I/O station: 4 stations
Remote device station: 8 stations
FX3U-64CCL
Intelligent device station for CC-Link
[1 to 4 stations occupied]
FX2N-32CCL
Remote device station for CC-Link
[1 to 4 stations occupied]
FX2N-64CL-M Master for CC-Link/LT
Model name Description
FX3G-5DM Display module that can be incorporated in FX3G Series main unit
Model name Description
FX
3G-232-BD For RS-232C communication
FX
3G-422-BD For RS-422 communication
FX
3G-485-BD For RS-485 communication
FX3G-8AV-BD For 8-ch Analog volume
FX3G-2AD-BD 2-ch voltage/current input
FX3G-1DA-BD 1-ch voltage/current output
Model name Description
FX3G-CNV-ADP Special adapter connection conversion adapter
D
D
E
F
G
