5. Input [X] / Output [Y] / Auxiliary Relay [M] / State [S]

19.14.8 Test operation on specified device monitor screen

To perform the test operation on the specified device monitor screen, it is necessary to turn ON M in the

system information (system signal 2).

The device test operation is same as the operation in the monitor/test mode.

→ Refer to Subsection 19.6.1 for the operation method.

X010 . . .34567

(Spec i f i ed)

M1 0 . . .34567

(Spec i f i ed)

00...
