Mitsubishi FX3G Series User Manual

15 Input/Output Powered Extension Units
15.6 FX2N-32ET, FX2N-48ET
205
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
11
High-Speed Counters
12
Output Wiring
13
Wiring for Various Uses
14
Test Run, Maintenance, Troubleshooting
15
Input/Output Powered Extension Units
16
Input/Output Extension Blocks
17
Extension Power Supply Unit
18
Other Extension Units and Options
19
Display Module
20
Terminal Block
15.6.2 External dimensions
FX2N-32ET
FX
2N-48ET
15.6.3 Terminal layout
FX2N-32ET
FX
2N-48ET
150 (5.91")
140 (5.52") (mounting hole pitch)
80 (3.15")
(mounting hole pitch)
90 (3.55")
9 (0.36")
Unit : mm (inches)
87 (3.43")
2-
4.5 mounting holes
182 (7.17")
172 (6.78") (mounting hole pitch)
80 (3.15")
(mounting hole pitch)
90 (3.55")
9 (0.36")
Unit : mm (inches)
87 (3.43")
2-
4.5 mounting holes
X0 COM
24+NL X1
X2
X3
X4
X5
X6
X7
X0
X1
X2
X3
X4
X5
X6
X7
Y4Y2
Y3
COM2
Y1
Y0
COM1
Y5
Y6
Y7
Y0
Y1
Y2
Y3
Y4
Y5
Y6
Y7
COM3 COM4
FX 2N -32ET
X0 COM
24+NL X1
X2
X3
X4
X5
X6
X7
X0
X1
X2
X3
X4
X5
X6
X7
Y4Y2
Y3
COM2
Y1
Y0
COM1
Y5
Y6
Y7
Y0
Y1
Y2
Y3
Y4
Y5
Y6
Y7
COM3 COM4
X0
X1
X2
X3
X4
X5
X6
X7
Y0
Y1
Y2
Y3
Y4
Y5
Y6
Y7
COM5
FX 2N -48ET
