Mitsubishi FX3G Series User Manual

3 Introduction of Products
3.1 List of Products and Interpretation of Model Names
33
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
1
Introduction
2
Features and Part Names
3
Product Introduction
4
Specifications
5
Version and Peripheral Devices
6
System Configuration
7
Input/Output Nos., Unit Nos.
8
Installation
9
Preparation and Power Supply Wiring
10
Input Wiring
3.1.11 FX Series terminal blocks (cables and connectors)
1. FX Series terminal blocks
2. Input/output cables
3. Input/output connector
3.1.12 Remote I/O
For the remote I/O of CC-Link and CC-Link/LT, refer to the manual and catalog of each master.
3.1.13 Power supply unit
Model name
Number of
input points
Number of
output points
Function
FX-16E-TB
16 input points or
16 output points
To be directly connected to the PLC input/output connector
FX-32E-TB
32 input points,
32 output points or
16 input/output points
FX-16EX-A1-TB 16 - 100V AC input
FX-16EYR-TB - 16 Relay output
FX-16EYS-TB - 16 Triac output
FX-16EYT-TB - 16 Transistor output (sink)
FX-16EYT-H-TB - 16 Transistor output (sink)
Model name Function
FX-16E-500CAB-S 5m(16’4") Bulk wire
FX-16E-150CAB 1.5m(4’11")
Flat cable (with tube). Both ends are provided with 20-pin connectors.FX-16E-300CAB 3m(9’10")
FX-16E-500CAB 5m(16’4")
FX-16E-150CAB-R 1.5m(4’11")
Round multicore cable. Both ends are provided with 20-pin connectors.FX-16E-300CAB-R 3m(9’10")
FX-16E-500CAB-R 5m(16’4")
FX-A32E-150CAB 1.5m(4’11")
Flat cable (with tube). The end on the PLC side is provided with two 20-pin connectors,
and the end on the terminal block side is provided with a exclusive connector. 1 common
terminal for 32 input/output points
FX-A32E-300CAB 3m(9’10")
FX-A32E-500CAB 5m(16’4")
Model name Function
FX2C-I/O-CON 10-piece set Input/output connector for flat cable
FX2C-I/O-CON-S 5-piece set
Input/output connector for bulk wire for 0.3 mm
2
[AGW22]
FX2C-I/O-CON-SA 5-piece set
Input/output connector for bulk wire for 0.5 mm
2
[AGW20]
Model name Description Driving power supply
FX
2N-20PSU 24V DC power supply 100 to 240V AC
M
N
