Mitsubishi FX3G Series User Manual

15 Input/Output Powered Extension Units
15.2 Power supply specifications
191
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
11
High-Speed Counters
12
Output Wiring
13
Wiring for Various Uses
14
Test Run, Maintenance, Troubleshooting
15
Input/Output Powered Extension Units
16
Input/Output Extension Blocks
17
Extension Power Supply Unit
18
Other Extension Units and Options
19
Display Module
20
Terminal Block
15.2 Power supply specifications
15.2.1 Weight, accessories, etc.
Item
FX2N-32ER-ES/UL
FX2N-32ET-ESS/UL
FX2N-32ER
FX2N-32ES
FX2N-32ET
FX2N-48ER-ES/UL
FX2N-48ET-ESS/UL
FX2N-48ER
FX2N-48ET
Classification FX2N powered extension unit
Supply voltage 100 to 240V AC
Allowable supply voltage range 85 to 264V AC
Rated frequency 50/60 Hz
Power fuse
250V 3.15A(3A) 5 x 20mm (0.79") 250V 5A 5 x 20mm (0.79")
Rush current
100V AC Up to 40A, 5ms or less
200V AC Up to 60A, 5ms or less
Power consumption 30W (35VA) 35W (45VA)
24V DC service
power supply
Without extension
block
24V DC, 250mA or less 24V DC, 460mA or less
With extension block
When input/output extension blocks are connected, 24V DC service power is consumed by
them.
→ For details, refer to Chapter 6.
Connection type Removable terminal block (M3 screw)
Item FX2N-48ER-UA1/UL
Classification FX2N powered extension unit
Supply voltage 100 to 240V AC
Allowable supply voltage range 85 to 264V AC
Power fuse
250V 5A 5 x 20mm (0.79")
Rush current
100V AC Up to 40A, 5ms or less
200V AC Up to 60A, 5ms or less
Power consumption 35W (45VA)
24V DC service power supply None
Connection type Removable terminal block (M3 screw)
Item
FX2N-32ER-ES/UL
FX2N-32ET-ESS/UL
FX2N-32ER
FX
2N-32ES
FX2N-32ET
FX2N-48ER-ES/UL
FX2N-48ET-ESS/UL
FX2N-48ER
FX2N-48ET
FX2N-48ER-UA1/UL
MASS (Weight) 0.65kg (1.43 lbs) 0.85kg (1.87 lbs) 1.00kg (2.2 lbs)
Accessories
• Terminal protective cover (2 pcs.)
(Fitted to FX
2N-32ER-ES/UL, FX2N-32ET-ESS/UL, FX2N-48ER-ES/UL, FX2N-48ET-ESS/UL and FX2N-48ER-
UA1/UL)
• Extension cable (55mm (2.16"))
Optional extension cables (FX0N-30EC and FX0N-65EC) are available.
• Input/output number label
Others
• The terminal block uses M3 terminal screws.
• Installation of the DIN46277 (35mm (1.37") wide) rail or screws.
