7 Assignment of Input/Output Numbers and Unit Numbers

7.2 Unit Numbers of Special Function Blocks

FX3G Series Programmable Controllers

User's Manual - Hardware Edition

7.2.3 Application of unit number labels

The special function units/blocks come with unit number labels.

Apply the unit number labels to spaces on the enclosure (see the following figure) so that the unit numbers

can be identified.

No.0

No.7

No.6

No.5

No.4

No.3

No.2

No.1

No.0

Y818D33101
