3 Introduction of Products
3.1 List of Products and Interpretation of Model Names
32
FX3G Series Programmable Controllers
User's Manual - Hardware Edition
3.1.8 Special adapters
3.1.9 Extension power supply unit
3.1.10 Extension cables and connector conversion adapter/ Battery/Memory cassettes
*1. When the extension cable (FX0N-30EC or FX0N-65EC) is used, use up to one cable for one system.
When an extension block is added, use FX2N-CNV-BC in addition to the cable.
Model name Description
FX3U-232ADP(-MB) RS-232C communication
FX3U-485ADP(-MB) RS-485 communication
FX3U-4AD-ADP 4-ch voltage/current input
FX3U-4DA-ADP 4-ch voltage/current output
FX3U-4AD-PT-ADP
4-ch platinum resistance thermometer sensor input (-50 to 250 C)
FX3U-4AD-PTW-ADP
4-ch platinum resistance thermometer sensor input (-100 to 600 C)
FX3U-4AD-PNK-ADP 4-ch Pt1000/Ni1000 resistance thermometer sensor input
FX3U-4AD-TC-ADP 4-ch thermocouple (K, J type) temperature sensor input
Model name Description Driving power supply
FX3U-1PSU-5V Extension power supply 5V DC 1A 100 to 240V AC
Classification Model name Description
Extension
cables
FX0N-65EC
*1
0.65m
(2’1")
These cables are used to mount input/output extension units/blocks for FX2N
and special function blocks away from the main unit.
FX0N-30EC
*1
0.3m
(0’11")
Connector
conversion
adapter
FX2N-CNV-BC
Connector conversion adapter to connect input/output extension blocks for FX2N and
special function blocks with model FX0N-30/65EC extension cable
Battery
FX3U-32BL
This battery backs up the following data.
• General devices (Parameter setting is required.)
- M1536 to M7679
- S1000 to S4095
- D1100 to D7999
- R0 to R23999
• Time on clock
Memory
cassettes
FX3G-EEPROM-32L 32k-step EEPROM memory (with transfer switch)
H
I
J
K
L
J
J
K
L
