Introduction
1-6 MPC823e REFERENCE MANUAL MOTOROLA
INTRODUCTION
1
• Development Capabilities and Interface
❏ Program Flow Tracking
— Instruction Show Cycle
— Data Show Cycle
— Branching
— Exception Traps
❏ Watchpoints and Breakpoints
— Four Hardware Breakpoints
— Five Watchpoint Sources
❏ Simple Hardware Interface
— High-Speed Data Transfer
— Internal Status Pins
— Freeze Indication
❏ Rich Control Register Set
• IEEE 1149.1 Test Access Port (JTAG)
• 3.3V Operation with 5V TTL Compatibility for the JTAG and Communication Processor
Module Port Pins and 3.3V for All Others.
• 256-Pin Plastic Ball Grid Array (BGA) Packaging
1.2 ARCHITECTURE
The MPC823e microprocessor uses a dual-processor architecture design approach with
large data and instruction caches to provide high performance using a general-purpose
RISC integer processor and a special-purpose 32-bit scalar RISC communication processor
module. The peripherals are uniquely designed for communication requirements and can
provide embedded signal processing functions for communication and user interface
enhancements and the I/O support needed for high-speed digital communications. The
MPC823e is comprised of four main modules that interface with the 32-bit internal bus:
• The embedded PowerPC core
• The system interface unit
• The communication processor module
• LCD controller
The MPC823e block diagram is illustrated in Figure 1-1.
